Image preview - the first page of the document
>> Download SONY service mode chassis FE-1 documenatation <<
Text preview - extract from the document
SELF-DIAGNOSTIC FUNCTION
SERVICE MANUAL FE-1 CHASSIS
MODEL COMMANDER DEST CHASSIS NO. MODEL COMMANDER DEST CHASSIS NO.
KV-25K5A RM-883 Italian SCC-Q06C-A
KV-29K5A RM-883 Italian SCC-Q06B-A
KV-25K5B RM-883 French SCC-Q02C-A KV-29K5B RM-883 French SCC-Q02B-A
KV-25K5D RM-883 AEP SCC-Q04C-A KV-29K5D RM-883 AEP SCC-Q04B-A
KV-25K5E RM-883 Spanish SCC-Q05C-A
KV-29K5E RM-883 Spanish SCC-Q05B-A
KV-25K5U RM-883 UK SCC-Q01C-A KV-29K5U RM-883 UK SCC-Q01B-A
/
MENU
PROGR
RM-883
