Image preview - the first page of the document
>> Download Sony HCD-GRX5 documenatation <<
Text preview - extract from the document
HCD-GRX5/RX66
SERVICE MANUAL US Model
Canadian Model
HCD-RX66
E Model
Australian Model
HCD-GRX5
HCD-GRX5/RX66 is the Amplifier, CD
player, Tape Deck and Tuner section in
MHC-GRX5/RX66. Photo: HCD-RX66
Dolby noise reduction manufactured under license Model Name Using Similar Mechanism HCD-H991AV
from Dolby Laboratories Licensing Corporation.
"DOLBY" and the double-D symbol a are trade- CDM38L-5BD29AL/
CD CD Mechanism Type
marks of Dolby Laboratories Licensing Corporation. CDM38LH-5BD29AL
Section
Base Unit Type BU-5BD29AL
Optical Pick-up Type KSS-213D/Q-NP
Model Name Using Similar Mechanism NEW
TAPE
DECK TCM-230AWR1/
Section Tape Transport Mechanism Type
230PWR1
SPECIFICATIONS
AUDIO POWER SPECIFICATIONS: Other models:
(U.S.A. model only) The following measured at AC 110, 220 V 50/60 Hz
DIN power output (rated) 50 + 50 watts
POWER OUTPUT AND TOTAL (6 ohms at 1 kHz, DIN)
HARMONIC DISTORTION: Continuous RMS power output (reference)
65 + 65 watts
with 6 ohm loads both channels driven, from 70 - 20,000 Hz; rates 60 (6 ohms at 1 kHz, 10% THD)
watts per channel minimum RMS power, with no more than 0.9% total The following measured at AC 120, 240 V 50/60 Hz
harmonic distortion from 250 milliwatts to rated output. DIN power output (rated) 60 + 60 watts
(6 ohms at 1 kHz, DIN)
Amplifier section Continuous RMS power output (reference)
Canadian model: 75 + 75 watts
Continuous RMS power output (reference) (6 ohms at 1 kHz, 10% THD)
60 + 60 watts Peak music power output (reference)
(6 ohms at 1 kHz, 10% THD) 1000 watts
Total harmonic distortion less than 0.07%
(6 ohms at 1 kHz, 45 W) Inputs
MD/VIDEO IN: voltage 450 mV,
(phono jacks) impedance 47 kilohms
MIX MIC: (phone jack) sensitivity 1 mV, impedance 10
kilohms
