Image preview - the first page of the document
>> Download Sony_service_manual_DSR-50_DSR-50P documenatation <<Text preview - extract from the document DSR-50/50P
SERVICE MANUAL US Model
Canadian Model
DSR-50
AEP Model
Ver 1.0 2000. 09 UK Model
E Model
Australian Model
New Zealand Model
DSR-50P
R MECHANISM
SPECIFICATIONS
System Inputs Outputs
Recording format DVCAM/DV (SP) format, rotating VIDEO/REF.IN BNC type VIDEO OUT1 BNC type, 1 Vp-p (75 ohms,
2-head helical scan, digital 1 Vp-p (75 ohms, unbalanced) unbalanced) (superimpose)
component recording S VIDEO IN Mini DIN 4-pin VIDEO OUT2 BNC type, 1 Vp-p (75 ohms,
Video signal Luminance signal: 1 Vp-p unbalanced)
DSR-50: EIA STANDARD, NTSC color (75 ohms, unbalanced) COMPONENT OUTPUT
system Chrominance signal: Y: BNC type
DSR-50P: CCIR STANDARD, PAL colour 0.286 Vp-p (DSR-50) 1 Vp-p (75 ohms, unbalanced)
system 0.3 Vp-p (DSR-50P) R-Y: BNC type
(75 ohms unbalanced) 0.7 Vp-p (75 ohms, unbalanced)
Video DV IN/OUT 6-pin IEEE-1394 standard jack (DSR-50: 75%, color bars / DSR-
Quantification 8-bit (i.LINK) 50P: 100%, colour bars)
Standardization frequency AUDIO INPUT (CH-1 to CH-4) B-Y: BNC type
DSR-50: 13.5 MHz (4:1:1 Component) XLR 3-pin, female, +4/
