Image preview - the first page of the document



>> Download sony chassis AE-5-2 documenatation <<

Text preview - extract from the document

SERVICE MANUAL                                                AE-5 CHASSIS
MODEL        COMMANDER   DEST       CHASSIS NO.   MODEL      COMMANDER    DEST       CHASSIS NO.




KV-28FX60A      RM-891    Italian    SCC-Q12D-A   KV-32FX60A     RM-891    Italian     SCC-Q12B-A


KV-28FX60B      RM-891    French     SCC-Q13D-A
                                                  KV-32FX60B     RM-891    French      SCC-Q13B-A


KV-28FX60D      RM-891    AEP        SCC-Q11D-A
                                                  KV-32FX60D     RM-891    AEP         SCC-Q11B-A


KV-28FX60E      RM-891    Spanish    SCC-Q14D-A   KV-32FX60E     RM-891    Spanish     SCC-Q14B-A


KV-28FX60K      RM-891    OIRT       SCC-Q16F-A
                                                  KV-32FX60K     RM-891    OIRT       SCC-Q16A-A


KV-28FX60R      RM-891    OIRT       SCC-Q16E-A
                                                  KV-32FX60R     RM-891    OIRT       SCC-Q16B-A


KV-28FX60U      RM-891    UK         SCC-Q15C-A   KV-32FX60U     RM-891    UK          SCC-Q15B-A




                                                          TRINITRON
