Image preview - the first page of the document
sony chassis RE-2-1


>> Download sony chassis RE-2-1 documenatation <<

Text preview - extract from the document
SERVICE MANUAL                                                                                                    RE-2 CHASSIS
MODEL
.................      COMMANDER DEST.
                      ........................... ............    CHASSIS NO.
                                                                 ..........................    MODEL
                                                                                              .................    COMMANDER DEST.
                                                                                                                  ........................... ............    CHASSIS NO.
                                                                                                                                                             ..........................



KP-41S5               RM-862                     AEP             SCC-N60C-A                   KP-41S5K            RM-862                     OIRT            SCC-N62D-A

KP-41S5B              RM-862                     French          SCC-N63B-A                   KP-41S5R            RM-862                     Russian         SCC-N62C-A

KP-41S5G              RM-862                     Greek           SCC-N60D-A                   KP-41S5U            RM-862                     UK              SCC-N61B-A




MICROFILM                                                                                                         PROJECTION TV
 Please file according to model size. .......
      41
KP-41S5/41S5B/41S5G/
  41S5K/41S5R/41S5U
                          RM-862



                                                           SPECIFICATIONS

  Television system      B/G/H,D/K,I,L                                  Front              q 3 S video input-4-pin DIN
  Colour system          PAL/SECAM                                                         ... 3 video inputs-phono jack
                         NTSC 3.58/NTSC4.43(VIDEO IN)
