Image preview - the first page of the document
SD-4980SC_SU


>> Download SD-4980SC_SU documenatation <<

Text preview - extract from the document
                           FILE NO. 810-200555




SERVICE MANUAL




    DVD VIDEO PLAYER
                 SD-4980SC
                 SD-4980SU




                                             July, 2005 A


                   DOCUMENT CREATED IN JAPAN, July, 2005
PARTS LIST
Location
         TSB P/N Reference No.                                               Description
  No.
        AH700347     043-000168-000 REMOTE CONTROL HANDSET SE-R0168 (C.G),
                                       w/o WEEE MARK         (PbF)
        AH700348     122-004220-120 AV CABLE1.2M COAXIAL
        AH700349     122-005020-005 HDMI CABLE 1500mm                                                         (For TC Version)
        AH700351     811-498091-010 MANUAL - English                                                          (For TC Version)
        AH700352     811-498091-020 MANUAL - French                                                           (For TC Version)
        AH700353     811-498091-030 MANUAL - Spanish                                                           (For TU Version)
        AH700354     811-498091-040 MANUAL - English                                                           (For TU Version)



        SAFETY PRECAUTION
        The parts identified by      mark are critical for safety. Replace only with part number specified.
        The mounting position of replacement is to be identical with originals. The substiute replacement
        parts which do not have the same safety characteristics as specified in the parts list may create
        shock, fire or other hazards.




        IN-WARRANTY SERVICE
        In-Warranty service for the SD4980 DVD Player is fulfilled via product
        exchange. Contact Toshiba Customer Solutions for instructions:
        1-866-583-7353
1-1, SHIBAURA 1-CHOME, MINATO- KU, TOKYO 105-8001, JAPAN
