Image preview - the first page of the document

>> Download hd_xa2_fw_inst2008_022_110 documenatation <<

Text preview - extract from the document
Toshiba Update Disc Part Number: HDX24000
Firmware Update Version: 4.0
              TOSHIBA HD-XA2 Firmware Update Disc Instructions
                          Thank you for selecting a TOSHIBA HD-DVD Video Player
  As part of our commitment to provide world-class service to our customers, TOSHIBA is supplying this firmware update disc
  for purchasers of TOSHIBA Model HD-XA2.
  The installation process is simple; however, please read all of the following instructions and notices prior to installation. This
  disc is intended solely for use with TOSHIBA Model HD-XA2.

  Notice (Read Prior to Beginning the Firmware Update Process)
  The following events may interrupt the firmware update process and cause the player to malfunction.
           1) DO NOT unplug the power cord during the firmware update process
           2) Avoid loss or interruption of power during the firmware update process
    !      3) DO NOT press the power button on the unit during the firmware update process
           4) Check the disc for dirt or scratches before beginning the firmware update process
  In the event that you have any questions regarding the firmware update process, please contact TOSHIBA Customer Solutions
  at 1-800-319-6684.

  Instructions (Begin Firmware Update)
        1) Confirm that the player is connected to a television. Turn on the television and select the appropriate video input on
            the television to view the player. (I.e. Video 1, Video 2, HDMI etc...)
        2) Turn the player on by pressing the "On / Standby" button" on the unit or with the remote control.
        3) Open the player's tray by momentarily pressing the "Open / Close" button on the front of the unit.
        4) Place the firmware update disc on the tray and close the disc drawer. The player will indicate "Loading" as the
            firmware update disc is initially read.
        5) The players front display will indicate "Ver Up" and the on-screen display will indicate "Do you want to update the
        6) If "Yes" is not already selected (Highlighted in yellow) select "Yes: by using the cursor left button on the remote
        7) Press "OK" on the user remote.
        8) If you receive a message "Error code : 2007c5c2" on the TV, this indicates you are using an incorrect firmware
            version. You should contact Toshiba Customer Solutions at 1-800-319-6684 to obtain the correct firmware version.
        9) After approx 2 minutes the players front display will indicate the progress of the firmware update in steps. It will first
            indicate "STEP 1/5" then "STEP 2/5", "STEP 3/5", "STEP 4/5" and finally "STEP 5/5".
        10) The player will stay on "STEP 5/5" for an extended period of time. During the update process the ON/STANDBY
            Led will flash between red and blue indicating that the update is in progress.
        11) The complete firmware update process will take approximately 15 minutes. DO NOT UNPLUG or POWER
            DOWN the Player during the update process or it may result in damage to the HD DVD Player. The disc tray
    !       will automatically open upon completion of the firmware update. The unit will shut off with the tray in the open
        12) Remove the update disc from the tray.
        13) Turn the player on by pressing the "On / Standby" button on the front of the unit. The disc tray will automatically
        14) When updating to this firmware version from some earlier releases you may be required to perform an additional step
            starting at step 15. This is indicated by the word "MSSG" on the front display of the player after the unit powers on. If
            the word "MSSG" does not appear your firmware update is now complete and you may stop now.
        15) If the word "MSSG" appears on the front display of the player the connected TV will display "Updating starts, Do not
            turn off during the update although no dialogues or screens will appear. After the update is complete, the power will
            automatically turn off." Press "OK" on the remote.
        16) DO NOT UNPLUG or POWER DOWN the Player during this update process or it may result in damage to the
            HD DVD Player.
        17) Wait for the player to power down by itself.. This may take approximately 10 minutes.
        18) Power on the Player.
        19) The firmware update is now completed.

                   1420-B Toshiba Dr. Lebanon, TN 37087            Fax: 615-444-0630
