Image preview - the first page of the document
>> Download hfe_toshiba_sd-210-eb-ee-el_service_en documenatation <<Text preview - extract from the document
FILE NO. 810-200103
DVD VIDEO PLAYER
Jun., 2001 5
LASER BEAM CAUTION LABEL
When the power supply is being turned on, you may not remove this laser cautions label. If it removes, radiation of a laser
may be recceived.
PREPARATION OF SERVICING
Pickup Head consists of a laser diode that is very susceptible to external static electricity.
Although it operates properly after replacement, if it was subject to electrostatic discharge during replacement,
its life might be shortened. When replacing, use a conductive mat, soldering iron with ground wire, etc. to
protect the laser diode from damage by static electricity.
And also, the LSI and IC are same as above.
wrist strap for body.
with ground wire
or ceramic type
The ground resistance
between the ground line
and the ground is less than 10 9 .
1. OPERATING INSTRUCTIONS 3. TROUBLESHOOTING
Specifications 3-1. Main Circuit
2. LOCATION OF MAIN PARTS AND 3-1-1. Servo System
MECHANISM PARTS 3-1-2. Location Diagram of Servo Test Point
2-1. Location of Main Parts
2-2. Location of Mechanism Parts
PART REPLACEMENT AND ADJUSTMENT PROCEDURES
1. REPLACEMENT OF MECHANICAL PARTS 1-3. Mechanism Parts
1-1. Cabinet Replacement 1-3-1. Mechanism Chassis Assembly
1-1-1. Top Cover 1-3-2. Loading Belt
1-1-2. Clamper Stay 1-3-3. Loading Motor
1-1-3. Tray Panel 1-3-4. Sub Chassis (with a pickup mechanism)
1-1-4. Front Panel and Tray 1-3-5. Pickup Mechanism Assembly
1-1-5. Rear Panel 1-3-6. Gear A Assembly, Gear B and
1-2. PC Board Replacement Rack Gear Assembly
1-2-1. Main PC Board 1-3-7. Feed Motor
1-2-2. Power PC board
1-2-3. Front PC Board
1-2-4. Output-RGB PC Board
1. STANDING PC BOARDS FOR SERVICING 5. CIRCUIT DIAGRAMS
2. CIRCUIT SYMBOLS AND 5-1. Power Supply Circuit Diagram
SUPPLEMENTARY EXPLANATION 5-2. Front Display, Power Switch Circuit Diagram
2-1. Precautions for Part Replacement 5-3. Main Circuit Diagram
2-2. Solid Resistor Indication 5-4. Output-RGB Circuit Diagram
2-3. Capacitance Indication 5-5. Motor System Circuit Diagrams
2-4. Inductor Indication 6. PC BOARDS
2-5. Waveform and Voltage Measurement 6-1. Power Supply PC Board
2-6. Others 6-2. Power Switch PC Board
3. PRINTED WIRING BOARD AND 6-3. Output-RGB PC Board
SCHEMATIC DIAGRAM 6-4. Main PC Board
4. BLOCK DIAGRAMS 6-5. Front Display PC Board
4-1. Overall Block Diagram
4-2. Power Supply Block Diagram
4-3. Front Display, Power Switch Block Diagram
4-4. Main Block Diagrams
4-5. Output-RGB Block Diagram
SAFETY PRECAUTION 4. EXPLODED VIEWS
NOTICE 4-1. Packing Assembly
ABBREVIATIONS 4-2. Chassis Assembly
1. Integrated Circuit (IC) 4-3. Mechanism Assembly
2. Capacitor (Cap) 5. PARTS LIST
3. Resistor (Res)
1. OPERATING INSTRUCTIONS (SD-210EB)
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE. DANGEROUS HIGH VOLTAGES ARE PRESENT INSIDE THE
ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALIFIED PERSONNEL
CAUTION: This Digital Video Disc Player employs a Laser System.
To ensure proper use of this product, please read this owner's manual carefully and retain for
future reference. Should the unit require maintenance, contact an authorized service location -
see service procedure.
Use of controls or adjustments or performance of procedures other than those specified herein
may result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try to open the enclosure.
Visible and invisible laser radiation when open and interlocks defeated.
DO NOT STARE INTO BEAM.
In the spaces provided below, record the Model and Serial No. located on the rear panel of your DVD video
Model No. Serial No.
Retain this information for future reference.
The following information applies only to SD-210EB, the model for U.K.
If the socket outlets in your home are not suitable for the plug supplied with this
unit, the plug must be cut off and an appropriate one fitted.
The plug severed from this mains lead must be destroyed as it is hazardous if
inserted into a live socket.
The wires in this mains lead are coloured in accordance with the following code:
As the colours of the wires in the mains lead of this unit may not correspond
with the coloured markings identifying the terminals in your plug, proceed as
The wire that is coloured blue must be connected to the terminal in the plug
which is marked with the letter N or coloured black.
The wire that is coloured brown must be connected to the terminal which is
marked with the letter L or coloured red.
Do not connect either wire to the earth terminal which is marked by the letter E
or by the safety earth symbol or coloured green or green-and-yellow.
Use a 5A fuse which is approved by ASTA or BSI to BS1362.
Always replace the fuse cover after changing the fuse.
Location of the required label
The rating plate and the safety caution are on the rear of the unit.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS GIVEN IN THIS
OWNER'S MANUAL AND THOSE MARKED ON THE UNIT. RETAIN THIS BOOKLET FOR
This set has been designed and manufactured to assure personal safety. Improper use can result in electric
shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following
procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that
can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGEROUS VOLTAGE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
10. Only use attachments/accessories specified by the manufacturer.
11.Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
12. Unplug this apparatus during lightning storms or when unused for long periods
IMPORTANT SAFETY INSTRUCTIONS
13. Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
14. When you use headphones, keep the volume at a moderate level. If you use
the headphones continuously with high volume sound, it may cause hearing
15. Do not overload wall outlets; extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
16. Never insert objects of any kind into this apparatus through openings as they
may touch dangerous voltage points or short-out parts that could result in a
fire or electric shock. Never spill liquid of any kind on the apparatus.
17. Keep your fingers well clear of the disc tray as it is closing. Neglecting to do
so may cause serious personal injury.
18. Do not place a heavy object on or step on the apparatus. The object may fall,
causing serious personal injury and serious damage to the apparatus.
19. Do not use a cracked, deformed, or repaired disc. These discs are easily
broken and may cause serious personal injury and apparatus malfunction.
Notes on handling Notes on moisture condensation
When shipping the DVD video player, the original Moisture condensation damages the DVD video
shipping carton and packing materials come in handy. player. Please read the following carefully.
For maximum protection, repack the unit as it was
Moisture condensation occurs, for example, when you
originally packed at the factory.
pour a cold drink into a glass on a warm day. Drops of
Do not use volatile liquids, such as insect spray, near
water form on the outside of the glass. In the same way,
the DVD video player. Do not leave rubber or plastic
moisture may condense on the optical pick-up lens
products in contact with the DVD video player for a
inside this unit, one of the most crucial internal parts of
long time. They will leave marks on the finish.
the DVD video player.
The top and rear panels of the DVD video player may
le of mo
become warm after a long period of use. This is not a Examp ensat isture
When the DVD video player is not in use, be sure to
remove the disc and turn off the power.
If you do not use the DVD video player for a long Optical pick-up
period, the unit may not function properly in the
future. Turn on and use the DVD video player
occasionally. Moisture condensation occurs during the
When you bring the DVD video player directly from a
Notes on locating cold place to a warm place.
When you use the DVD video player in a room where
Place the DVD video player on a level surface. Do not you just turned on the heater, or a place where the
use it on a shaky or unstable surface such as a cold wind from the air conditioner directly hits the unit.
wobbling table or inclined stand. The loaded disc may In summer, when you use the DVD video player in a
come off the proper position and cause damage to hot and humid place just after you move the unit from
the DVD video player. an air conditioned room.
When you place this DVD video player near a TV, When you use the DVD video player in a humid place.
radio, or VTR, the playback picture may become poor
and the sound may be distorted. In this case, place
the DVD video player away from the TV, radio, or warm!
Notes on cleaning
Use a soft, dry cloth for cleaning.
For stubborn dirt, soak the cloth in a weak detergent
solution, wring well and wipe. Use a dry cloth to wipe Do not use the DVD video player when moisture
it dry. condensation may occur.
Do not use any type of solvent, such as thinner and If you use the DVD video player in such a situation, it
benzine, as they may damage the surface of the DVD may damage discs and internal parts. Remove the
video player. disc, connect the power cord of the DVD video player
If you use a chemical saturated cloth to clean the unit, to the wall outlet, turn on the DVD video player, and
follow that product's instructions. leave it for two or three hours. After two or three
hours, the DVD video player will have warmed up and
evaporated any moisture. Keep the DVD video player
To obtain a clear picture connected to the wall outlet and moisture
condensation will seldom occur.
The DVD video player is a high technology, precision
device. If the optical pick-up lens and disc drive parts Wa
are dirty or worn down, the picture quality becomes it!
poor. To obtain a clear picture, we recommend regular
inspection and maintenance (cleaning or parts
replacement) every 1,000 hours of use depending on
the operating environment. For details, contact your
Notes on Discs
On handling discs Structure of disc contents
Do not touch the playback side of the disc. Normally, DVD video discs are divided into titles, and
the titles are sub-divided into chapters. VIDEO CDs and
audio CDs are divided into tracks.
DVD video disc
DVD video disc
Title 1 Title 2
Chapter 1 Chapter 2 Chapter 1 Chapter 2 Chapter 3
Do not attach paper or tape to discs.
VIDEO CD/audio CD
VIDEO CD/audio CD
Track 1 Track 2 Track 3 Track 4 Track 5
On cleaning discs
Fingerprints and dust on the disc cause picture and
sound deterioration. Wipe the disc from the center Each title, chapter or track is assigned a number, which
outwards with a soft cloth. Always keep the disc is called "title number", "chapter number" or "track
clean. number" respectively.
There may be discs that do not have these numbers.
Notes on copyright
It is forbidden by law to copy, broadcast, show,
broadcast on cable, play in public, and rent copyrighted
If you cannot wipe off the dust with a soft cloth, wipe material without permission.
the disc lightly with a slightly moistened soft cloth and
finish with a dry cloth. DVD video discs are copy protected, and any recordings
Do not use any type of solvent such as thinner, made from these discs will be distorted.
benzine, commercially available cleaners or antistatic
spray for vinyl LPs. It may damage the disc. This product incorporates copyright protection
technology that is protected by method claims of certain
U.S. patents and other intellectual property rights owned
On storing discs by Macrovision Corporation and other rights owners.
Use of this copyright protection technology must be
Do not store discs in a place subject to direct sunlight authorized by Macrovision Corporation, and is intended
or near heat sources. for home and other limited viewing uses only unless
Do not store discs in places subject to moisture and otherwise authorized by Macrovision Corporation.
dust such as a bathroom or near a humidifier. Reverse engineering or disassembly is prohibited.
Store discs vertically in a case. Stacking or placing
objects on discs outside of their case may cause
Notes on Discs (continued)
About this owner's manual Playable discs
This owner's manual explains the basic instructions of This DVD video player can play the following discs.
this DVD video player. Some DVD video discs are
produced in a manner that allows specific or limited Disc Maximum
Disc Mark Contents Size playback time
operation during playback. As such, the DVD video
player may not respond to all operating commands. This Approx. 4 hours
is not a defect in the DVD video player. Refer to (single sided disc)
instruction notes of discs. 12 cm
Audio Approx. 8 hours
" " may appear on the TV screen during operation. + (double sided disc)
A " " means that the operation is not permitted by the video (moving
DVD video player or the disc. discs pictures) Approx. 80 minutes
(single sided disc)
Notes on region numbers Approx. 160 minutes
(double sided disc)
The region number of this DVD video player is 2. If
region numbers, which stand for their playable area, are
printed on your DVD video disc and you do not find 2 12 cm Approx. 74 minutes
or ALL , disc playback will not be allowed by the player. +
(In this case, the DVD video player will display a video
message on-screen.) DIGITAL VIDEO
8 cm Approx. 20 minutes
On VIDEO CDs
This DVD video player supports VIDEO CDs equipped 12 cm Approx. 74 minutes
with the PBC (Version 2.0) function. (PBC is the Audio
abbreviation of Playback Control.) You can enjoy two CDs 8 cm
playback variations depending on types of discs. (CD Approx. 20 minutes
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
