Image preview - the first page of the document
Installation_Instruction


>> Download Installation_Instruction documenatation <<

Text preview - extract from the document
How to upgrade the Software

Whenever updating the Software, perform the "Media Player setup" as below.
Otherwise software updating may not be stared.


1   Press the "MENU" button on the remote controller.
    Via LEFT/RIGHT or UP/DOWN button on the remote controller, select
         "Media Player"
         "USB Media Player"
         "Setup"




        Note; "Setup" may not be visible until you select it through "USB Media Player" menu.


2   Press the "left or right" arrow buttons to select the "On" as shown in figure2.




                                                    Figure2

3   Press "EXIT" button on the remote controller to exit the "Menu".




Copyright 2010                                          All Rights Reserved                Page 1 of 4



4   Connect the AC power and turn "ON" the TV receiver.


5   The USB reader is located on the left or right of the cabinet near the side control/jack assembly as
    shown in Figure1.




                                                Figure3


6   Insert the "USB Drive" into the USB slot as shown in Figure2.




                                                Figure4




Copyright 2010                                        All Rights Reserved                  Page 2 of 4
 7   After insertion of USB Drive into reader slot a firmware upgrade information window will appear as
     shown in Figure5.




                                                     Figure5


 8   If the window is no present, remove the USB Drive and try reinserting the USB Drive again.


 9   Press the "left or right arrow" buttons on the remote controller to select the "Yes".
     Press the "OK" button on the remote controller.
     Following message will appear in sequence of figure 6 and 7.




                                                     Figure6




                                                     Figure7


10 Press the "left or right arrow" buttons on the remote controller to select the "Yes".

11 Press the "OK" button on the remote controller to start the Software updating.




 Copyright 2010                                          All Rights Reserved                 Page 3 of 4
12 Following message will appease as shown in figure 8 and then disappear.




                                                    Figure8

     While the TV is upgrading no indication will appear on the TV screen but the upgrade is in process.
     This will take approx.3 minutes.
     DO NOT unplug the AC power to the TV or press any buttons on the remote controller or the TV
     keypad during this process.


13 Upon completion of the software upgrade, The TV will reboot automatically.
14 Following massage will appear again after 20 seconds as shown in figure 9.




                                                    Figure9


15 Press the "left or right arrow" buttons on the remote controller to select the "Yes".
     Following massage will appear as shown in figure 9 and then disappear.




16 Remove the "USB Drive" from the slot.
     Momentarily remove (10 seconds) AC power from set by unplugging the AC power cord.
     Plug the TV back into the AC power. The TV should turn back on.

     Now select Menu
