Image preview - the first page of the document
>> Download Compal ISRAE LA-3711P(2) documenatation <<
Text preview - extract from the document
A B C D E
1 1
Compal Confidential
2 2
ISRAE LA-3711P Schematics Document
Intel Yonah/Merom with 945GM/943GML/940GML+ DDRII + ICH7M
3
2007-01-29 3
REV: 0.2
4 4
Security Classification Compal Secret Data Compal Electronics, Inc.
Issued Date 2006/10/31 Deciphered Date 2009/11/13 Title
THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL
Cover Sheet
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
Size Document Number Rev
0.2
DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.
ISRAE M/B LA-3711P
Date: Tuesday, February 06, 2007 Sheet 1 of 39
A B C D E
A B C D E
Compal confidential
Model : ISRAE Fan Control
page 4
Yonah/Merom Thermal Sensor Clock Generator
File Name : LA-3711P uFCPGA-478 CPU ICS9LPRS325AKLFT
ADM1032ARM
NAPA Platform page 4,5,6 page 4 page 14
1 1
H_A#(3..31)
FSB
H_D#(0..63)
LCD Conn. CRT & TV-out 533/667MHz
page 16 page 16
Intel Calistoga GMCH DDR2-533/667 DDR2-SO-DIMM X2
BANK 0, 1, 2, 3 page 12, 13
NVIDIA NB7P-GS 945PM/GM
NB7M-SE VGA/B Conn. Dual Channel
with 128/256 PCI-Express PCBGA 1466
page 15 page 7,8,9,10,11
MB VRAM x16
PCI-E BUS 2.5GHz USB1.1 USB Bluetooth Carema USB x 2 USB/B conn
Finger page 25
Print page 25 page 25
conn x 1 28
page page 25
DMI x 4
(port 3)
2 USB port 7 USB port 6 USB port 5 USB port 2,4 USB port 0, 1 2
USB port 3 USB 3.3V 480MHz
10/100/1000 LAN New Card Slot
RTL8111B/RTL8101E
page 22
page 27
Intel ICH7-M Azalia 3.3V 24.576MHz/48Mhz
MDC1.5
page 24
Mini Express Card mBGA-652 SATAI/II 1.5GHz/3G
RJ45/11 CONN page 25 page 16,17,18
Audio Codec AMP & Audio Jack & Int-MIC
page 22 3.3V 33 MHz PATA 3.3V ATA-100 ALC861D SPK/JP-AMP: APA2056
PCI BUS page 23
page 24
SATA HDD Connector
CardBus Controller SATA 0
page 16
TI PCI8412/8402
page 20,21
3 LPC BUS SATA HDD Connector ISRAE Sub-board
3
3.3V 33 MHz SATA 1
page 16
Slot 0 1394 port 5in1 Slot SW/B
page 21 page 20 page 20 PATA Master
PATA ODD Connector
page 16
LS-3441P Rev1
LED ENE KB910 CRT/B
page 28
page 26
LS-3448P Rev1
RTC CKT. USB/B
page 16
LS-3444P Rev1
Power On/Off CKT. Touch Pad Int.KBD BIOS
4
page 28 page 25 page 28 page 27 Finger Printer/B 4
LS-3401P Rev1
DC/DC Interface CKT.
page 29
Security Classification Compal Secret Data Compal Electronics, Inc.
Issued Date 2006/10/31 Deciphered Date 2009/11/13 Title
Power Circuit DC/DC THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL
Block Diagram
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
Size Document Number Rev
Page 30~36 0.2
DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.
ISRAE M/B LA-3711P
Date: Tuesday, February 06, 2007 Sheet 2 of 39
A B C D E
A B C D E
Voltage Rails Board ID / SKU ID Table for AD channel
Vcc 3.3V +/- 5%
Power Plane Description S1 S3 S5 Ra 100K +/- 5%
Board ID Rb V AD_BID min V AD_BID typ V AD_BID max
VIN Adapter power supply (19V) N/A N/A N/A
B+ AC or battery power rail for power circuit. N/A N/A N/A
0 0 0 V 0 V 0 V
1
+CPU_CORE Core voltage for CPU ON OFF OFF
1 8.2K +/- 5% 0.216 V 0.250 V 0.289 V 1
+0.9VS 0.9V switched power rail for DDR terminator ON OFF OFF
2 18K +/- 5% 0.436 V 0.503 V 0.538 V
+VCCP 1.05V switched power rail ON OFF OFF
3 33K +/- 5% 0.712 V 0.819 V 0.875 V
+1.5VS 1.5V switched power rail ON OFF OFF
4 56K +/- 5% 1.036 V 1.185 V 1.264 V
+1.8V 1.8V power rail for DDR ON ON OFF
5 100K +/- 5% 1.453 V 1.650 V 1.759 V
+1.8VS 1.8V switched power rail ON OFF OFF
6 200K +/- 5% 1.935 V 2.200 V 2.341 V
+2.5VS 2.5V switched power rail ON OFF OFF
7 NC 2.500 V 3.300 V 3.300 V
+3VALW 3.3V always on power rail ON ON ON*
+3VS 3.3V switched power rail ON OFF OFF
BOARD ID Table BTO Option Table
+5VALW 5V always on power rail ON ON ON*
+5VS 5V switched power rail ON OFF OFF Board ID PCB Revision BTO Item BOM Structure
+VSB +VSB always on power rail ON ON ON* 0 0.1 45 level 45@
+RTCVCC RTC power ON ON ON 1 2ND HDD 2HDD@
2 LAN 100M@/1000M@
3 WLAN KS@
4 MDC MDC@
2 2
5 Blue tooth BT@
6 Card ctrller 8412@/8402@/4512@
Note : ON* means that this power plane is ON only with AC power available, otherwise it is OFF.
7 FINGER PRINT FP@
5IN1 5IN1@, NON5IN1@
External PCI Devices SKU ID Table Express card NEWCARD@
PCMCIA PCMCIA@
DEVICE PCI Device ID IDSEL # REQ/GNT # PIRQ
SKU ID SKU Carema+MIC CAREMA@
1394 D0 AD20 2 A ,B,C 0 10 (10E)(10M) VGA FAN FAN2@
CARD BUS D4 AD20 2 A ,B,C 1 10C CHIPSET (R3) GMLR3@,GM@,ICH7R3@
5IN1 D4 AD20 2 A ,B,C 2 10G(10MG) change R3 to GMR3@,GM@,ICH7R3@
3 10GC R1 for FRU PMR3@,PM@,ICH7R3@
4 10J(10EJ) (10MJ) CIR CIR@
5 10CJ Energy Star ENG@
6 10G(10MG)J
KB910 I2C / SMBUS ADDRESSING 7 10GC(10MGC)J
DEVICE HEX ADDRESS
3 3
SM1 24C16 A0H 1010000Xb
SM1 SMART BATTERY 16H 0001011Xb
SM2 ADM0132 98H 1001100Xb
CPU THERMAL MONITOR
ICH7-M SM Bus address
DEVICE HEX ADDRESS
DDR SO-DIMM 0 A0 10100000
DDR SO-DIMM 1 A4 10100100
CLOCK GENERATOR (EXT.) D2 11010010
4 4
Security Classification Compal Secret Data Compal Electronics, Inc.
Issued Date 2006/10/31 Deciphered Date 2009/11/13 Title
THIS SHEET OF ENGINEERING DRAWING IS THE PROPRIETARY PROPERTY OF COMPAL ELECTRONICS, INC. AND CONTAINS CONFIDENTIAL
Notes
AND TRADE SECRET INFORMATION. THIS SHEET MAY NOT BE TRANSFERED FROM THE CUSTODY OF THE COMPETENT DIVISION OF R&D
Size Document Number Rev
0.2
DEPARTMENT EXCEPT AS AUTHORIZED BY COMPAL ELECTRONICS, INC. NEITHER THIS SHEET NOR THE INFORMATION IT CONTAINS
MAY BE USED BY OR DISCLOSED TO ANY THIRD PARTY WITHOUT PRIOR WRITTEN CONSENT OF COMPAL ELECTRONICS, INC.
ISRAE M/B LA-3711P
Date: Tuesday, February 06, 2007 Sheet 3 of 39
A B C D E
5 4 3 2 1
+3VS
Thermal Sensor ADM1032ARM Place close to CPU within 500mil
+VCCP
7 H_A#[3..31] H_D#[0..63] 7
JP1A 1
H_A#3 J4 E22 H_D#0 C1 XDP_TDI 1 R88 2
H_A#4
H_A#5
L4
A3#
A4#
YONAH D0#
D1# F24 H_D#1
H_D#2 2
0.1U_0402_16V4Z
XDP_TMS
56_0402_5%
M3 A5# D2# E26 1 1 R84 2
H_A#6 K5 H22 H_D#3 56_0402_5%
H_A#7 A6# D3# H_D#4 C2 U1
M1 A7# D4# F23
H_A#8 N2 G25 H_D#5 2200P_0402_50V7K H_THERMDA 2 1
D H_A#9 A8# D5# H_D#6 2 D+ VDD1 XDP_BPM#5 D
J1 A9# D6# E25 1 R83 2
H_A#10 N3 E23 H_D#7 H_THERMDC 3 6 56_0402_5%
H_A#11 A10# D7# H_D#8 D- ALERT# XDP_TRST#
P5 A11# D8# K24 1 R90 2
H_A#12 P2 G24 H_D#9 8 4 56_0402_5%
A12# D9# 15,26 EC_SMB_CK2 SCLK THERM#
H_A#13 L1 J24 H_D#10 XDP_TCK 1 R102 2
H_A#14 A13# D10# H_D#11 56_0402_5%
P4 A14# D11# J23 15,26 EC_SMB_DA2 7 SDATA GND 5
H_A#15 P1 H26 H_D#12
H_A#16 A15# D12# H_D#13
R1 A16# D13# F26
H_A#17 Y2 K22 H_D#14 ADM1032ARM_RM8
H_A#18 A17# D14# H_D#15 +5VS
U5 A18# D15# H25
H_A#19 R3 N22 H_D#16
H_A#20 A19# D16# H_D#17
W6 A20# D17# K25
H_A#21 U4 P26 H_D#18
H_A#22 A21# D18# H_D#19 P@
Y5 A22# D19# R23
8
1SS355_SOD323
H_A#23 U2 L25 H_D#20 PU5B LM358DT_SO8
A23# D20#
1
H_A#24 R4 L22 H_D#21 26 EN_DFAN1 5 + C
P
A24# D21#
1
H_A#25 T5 ADDR GROUP DATA GROUP L23 H_D#22 7 1 R674 2 FAN1_ON 2 Q50
H_A#26 A25# D22# H_D#23 R594 2 0 100_0402_5% C820 B FMMT619_SOT23
T3 A26# D23# M23 1 6 -
G
H_A#27 W3 P25 H_D#24 10K_0402_5% 1 2 E D36
3
H_A#28 A27# D24# H_D#25
W5 P22
4
H_A#29 A28# D25# H_D#26 0.1U_0402_16V4Z
Y4 P23
2
H_A#30 A29# D26# H_D#27 @
W2 A30# D27# T24
H_A#31 Y1 R24 H_D#28 1 R439 2 +FAN1_VOUT
7 H_REQ#[0..4] A31# D28#
L26 H_D#29 8.2K_0402_5%
D29#
1
1N4148_SOT23
H_REQ#0 K3 T25 H_D#30
H_REQ#1 REQ0# D30# H_D#31 D37
H2 REQ1# D31# N24
H_REQ#2 K2 AA23 H_D#32
H_REQ#3 REQ2# D32# H_D#33
J3 REQ3# D33# AB24
H_REQ#4 H_D#34 JP2
L5 V24
2
REQ4# D34# H_D#35
D35# V26 1 1
H_ADSTB#0 L2 W25 H_D#36 2
7 H_ADSTB#0 ADSTB0# D36# 2
H_ADSTB#1 V4 U23 H_D#37 3
C 7 H_ADSTB#1 ADSTB1# D37# 3 C
U25 H_D#38 +3VS 1 2 R440
D38# H_D#39 10K_0402_5%
D39# U22 4 GND
AB25 H_D#40 5
D40# H_D#41 GND
D41# W22 26 FAN_SPEED1 1
Y23 H_D#42 1 ACES_85205-03001
CLK_CPU_BCLK A22 D42# H_D#43 C633
14 CLK_CPU_BCLK BCLK0 D43# AA26
CLK_CPU_BCLK# A21 HOST CLK Y26 H_D#44 C632 @1000P_0402_50V7K
14 CLK_CPU_BCLK# BCLK1 D44# H_D#45 @1000P_0402_50V7K 2
D45# Y22
H_D#46 2
D46# AC26
AA24 H_D#47
H_ADS# D47# H_D#48 VS
7 H_ADS# H1 ADS# D48# AC22
H_BNR# E2 AC23 H_D#49 C1005
7 H_BNR# BNR# D49# +5VS
H_BPRI# G5 AB22 H_D#50 1 2
7 H_BPRI# BPRI# D50#
H_BR0# F1 AA21 H_D#51
7 H_BR0# BR0# D51#
H_DEFER# H5 AB21 H_D#52 0.1U_0402_16V4Z
7 H_DEFER# DEFER# D52#
1SS355_SOD323
H_DRD Y# F21 AC25 H_D#53 FAN2@
7 H_DRDY# DRDY# D53#
H_HIT# G6 AD20 H_D#54 FAN2@
7 H_HIT# HIT# D54#
8
1
R100 H_HITM# E4 CONTROL AE22 H_D#55 U41A LM358DT_SO8
7 H_HITM# HITM# D55#
1
1 2 H_IERR# D20 AF23 H_D#56 26 EN_DFAN2 3 + C
P
+VCCP 56_0402_5% H_LOCK# IERR# D56# H_D#57 R867 2 FAN2_ON 2 Q83 D56
7 H_LOCK# H4 LOCK# D57# AD24 0 1 1
