Image preview - the first page of the document
>> Download SATELLITE 1800 SERIES documenatation <<
Text preview - extract from the document
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Satellite
1800 Series
GENERAL INFORMATION
Tools Required for Proper
Disassembly and Reassembly:
1. Phillips Screwdriver (Size 1)
2. 5mm Flat head Screwdriver
3. Case Separator
4. ESD Wrist Strap
5. ESD mats
6. Tweezers
Before attempting any of the following procedures,
make sure that the main battery and AC adaptor is
not connected to the unit and the environment in
which you are working on is protected from
Electro-Static Discharge(ESD).
TOSHIBA
Tough Enough for Today's World
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Satellite
1800 Series
TABLE OF CONTENTS:
1. BATTERY PACK REMOVAL
2. OPTIONAL PC CARD REMOVAL
3. HDD REMOVAL
4. MEMORY MODULE REMOVAL
5. MINI PCI CARD REMOVAL
6. MODEM BOARD REMOVAL
7. KEYBOARD REMOVAL
8. IPS SWITCH REMOVAL
9. COOLING MODULE REMOVAL
10. CPU REMOVAL
11. DVD-ROM/CD-ROM DRIVE REMOVAL
12. TOP COVER REMOVAL
13. HDD/BATTERY BOARD REMOVAL
14. RTC BATTERY REMOVAL
15. VOLUME CONTROL BOARD REMOVAL
16. SPEAKERS REMOVAL
17. FDD REMOVAL
18. LED BOARD REMOVAL
19. SYSTEM BOARD REMOVAL
20. 13.3' DISPLAY MASK REMOVAL
21. FL INVERTER AND 13.3' LCD REMOVAL
22. 14'' DISPLAY MASK REMOVAL
23. FL INVERTER AND 14'' LCD REMOVAL
TOSHIBA
Tough Enough for Today's World
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Satellite
1800 Series
BATTERY PACK REMOVAL OPTIONAL PC CARD REMOVAL
PC card
Battery
Battery pack release lever PC card lock
Eject button
1. Turn the computer upside down as shown. 1. Slide the PC Card lock to unlock position
2. Slide the battery release lever in the direction of the 2. Press the eject button to pop it out.
arrow. 3. Press the eject button and remove the PC card.
3. Slide the battery pack to the right and lift it out. NOTE: Before removing any PCCARD device, make
sure it is "STOPPED" in the PC Card Manager.
HDD REMOVAL
HDD assembly
M2.5x4 black HDD bracket handle
HDD slot cover flat head screw
M2.5x4 black flat head screw
1. Turn the computer upside down. 3. Remove one M2.5x4 black flat head screw
2. Remove one M2.5x4 black flat head screw securing securing the HDD assembly.
HDD slot cover and pull out the cover. 4 Grasp the HDD bracket handle and pull to
disconnect the HDD assembly.
. 5. Lift the HDD assembly out of the HDD bay.
TOSHIBA
Tough Enough for Today's World
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Satellite
1800 Series
HDD REMOVAL MEMORY MODULE REMOVAL
M2.5x4 black
flat head screws Memory cover
Memory
module
M3x4 Flat head screws
HDD bracket
Memory clips
6. Remove four M3x4 flat head screws securing the 1. Turn the computer upside down.
HDD bracket to the drive. 2. Remove two M2.5x4 black flat head screws and
remove the memory cover.
3. Push the memory clips outward and pull the
memory module out of the connector on a
30 degree angle.
MINI PCI CARD REMOVAL
PCI clips
M2.5x4
black torx
screws
Mini PCI card
Mini PCI slot cover
1. Turn the computer upside down. 3. Push the mini PCI slot clips outward and pull the
2. Remove two M2.5x4 black torx screws securing the mini mini PCI card out of the connector on a 45 degree
PCI slot cover. angle.
TOSHIBA
Tough Enough for Today's World
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Satellite
1800 Series
MODEM REMOVAL
M2x4 brass screws
RJ11 Jack
Modem slot cover M2.5x4 black flat head screw Modem
1. Remove one M2.5x4 black flat head screw securing 3. Remove the glass tape securing the RJ-11 jack cable.
the modem slot cover. 4. Remove two M2x4 brass screws securing the
2. Insert the case separator into the notched side of the modem board.
cover and lift up to release the two latches securing 5. Lift up the modem board to disconnect it from the
the left side of the modem slot cover. system board.
6. Remove the RJ-11 jack from the modem board.
KEYBOARD REMOVAL
Latch
Keyboard holder M2.5x2.6 black screws
1. Open the display panel. 3. Remove two M2.5x2.6 black screws securing the
2. Remove the Keyboard holder at the top of the keyboard.
keyboard.
TOSHIBA
Tough Enough for Today's World
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Satellite
1800 Series
KEYBOARD REMOVAL IPS SWITCH REMOVAL
PJ333
Keyboard
cable
Keyboard M2.5x4 black flat head screw IPS switch cover
4. Lift out the keyboard and set it on the palm rest. 1. Remove one M2.5x4 black flat head screw securing
5. Disconnect the keyboard cable from PJ333 on the the IPS switch cover(touchpad) from the battery
system board and lift out the keyboard. compartment.
2. Remove the IPS switch(touchpad) cover from the
palm rest.
IPS SWITCH REMOVAL COOLING MODULE REMOVAL
PJ339
IPS switch
cable
Membrane
switch
assy
M2.5x6 black flat head screws Heat sink plate
3. Disconnect the IPS switch cable from PJ339 on the 1. Remove four M2.5x6 black flat head screws
system board and lift out the membrane switch assembly. securing the heat sink plate.
2. Lift out the heat sink plate.
TOSHIBA
Tough Enough for Today's World
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Satellite
1800 Series
COOLING MODULE REMOVAL CPU REMOVAL
Flat head
screwdriver
Cooling
module
Fan cable
CPU
PJ770
lock
CPU
M2x16 brass screws Silicone grease
3. Remove four M2x16 brass screws securing the 5. Slide the CPU lock in the direction of the arrow.
cooling module. 6. Insert a 5mm flat head screwdriver on the top side
4. Disconnect the fan cable from PJ770 from the of the CPU socket and push the socket in the
system board and lift out the Fan module. direction of the arrow and lift out the CPU.
NOTE: When installing the CPU make sure that a silicone
grease is applied before attaching the cooling
module. Please refer to FSB-200112 for the complete
procedures on how to apply the silicone grease.
.
CD-ROM/DVD ROM DRIVE REMOVAL
CD/DVD-ROM Brass washers
drive
CD/DVD-ROM drive
bracket
M2x2 silver screws
M2x5.5 silver screws
1. Remove two M2x5.5 silver screws securing the CD-ROM/ 3. Remove two M2x2 silver screws and two brass
DVD ROM drive. washers securing the CD/DVD- ROM drive bracket.
2. Slide the CD/DVD-ROM drive to the right to disconnect
it from PJ321 on the system board.
TOSHIBA
Tough Enough for Today's World
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Satellite
1800 Series
TOP COVER REMOVAL
M2.5x4 black screws M2.5x25 black screws Top cover
assembly
M2.5x25
black
M2.5x6
screws
black
screws
M2.5x6 M2.5x20
black black
screws screws
Flexible cable PJ426 PJ34 LCD/FL cable
M2.5x4 black screws 2. Turn the computer right side up and open the LCD
1. Turn the computer upside down and remove the panel.
following seventeen screws: 3. Remove one M2.5x6 black screws and two 2.5x25
- 5 M2.5x4 black flat head screws black screws securing the top cover assembly.
- 4 M2.5x6 black flat head screws 4. Disconnect the LCD/FL cable from PJ34 and the
- 5 M2.5x20 black screws CD-ROM controller flexible cable from PJ426.
- 3 M2.5x25 black screws 5. Remove the top cover assembly by lifting up the
back side of the cover.
HDD/BATTERY BOARD REMOVAL RTC REMOVAL
HDD/Battery
board cable
PJ752
PJ4
Glass
HDD/Battery tape
board
PJ2 Right speaker cable RTC battery cable RTC battery
1. Disconnect the HDD/Battery board cable from PJ4 1. Remove the glass tape securing the RTC battery.
on the HDD/Battery board. 2. Disconnect the RTC battery cable from PJ752 on
2. Disconnect the right speaker cable from PJ2 on the the system board.
HDD/Battery board. 3. Lift out the RTC battery.
3. Disconnect the HDD/Battery board from PJ320 on
the system board.
TOSHIBA
Tough Enough for Today's World
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Satellite
1800 Series
VOLUME CONTROL BOARD REMOVAL SPEAKERS REMOVAL
Volume
control cable
M2.5x4
black
flat head
screws Left Right
speaker speaker
Volume control board Speaker cable M2.5x6 Silver screws
1. Remove two M2.5x4 black flat head screws securing 1. Remove four M2.5x6 silver screws securing both
the volume control board. the left and right speakers.
2. Disconnect the volume control cable from PJ61 and 2. Lift out both speakers.
the left speaker cable from PJ60 on the volume control
board.
FDD REMOVAL
PJ344 FDD cable
FDD cable
FDD assy
M2x3 silver screws
M2.5x6 silver screws
1. Disconnect the FDD cable from PJ344 on the 4. Remove three M2.5x3 black screws securing the
system board. FDD to the FDD case and separate the FDD from
2. Remove two M2.5x6 silver screws securing the the case.
FDD assembly. 5. Disconnect the FDD cable from the FDD.
3. Lift out the FDD assembly.
TOSHIBA
Tough Enough for Today's World
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Satellite
1800 Series
LED BOARD REMOVAL SYSTEM BOARD REMOVAL
CD-ROM
insulator
LED board Conn holder M2.5x6 silver screws
1. Lift up the LED board to disconnect it from PJ310 1. Remove two M2.5x6 silver screws securing the
on the system board. conn holder.
2. Lift out the conn holder.
SYSTEM BOARD REMOVAL
PJ810
DC-jack Battery harness
harness
System board
PJ800
Hex screws
M2.5x4 PJ3
black flat head
screws Flexible cable
3. Disconnect the DC-jack harness from PJ800 on the 5. Remove the system board by lifting up from the front
system board. side as shown above.
4. Remove two hex screws and three M2.5x4 black 6. Disconnect the flexible cable and battery harness
flat ehad screws securing the system board. from PJ3 and PJ810 on the system board.
TOSHIBA
Tough Enough for Today's World
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Satellite
1800 Series
13.3" DISPLAY MASK REMOVAL FL INVERTER AND 13.3" LCD REMOVAL
LCD module
Latch
Display M2x5
M2x3 silver
mask
silver screws
screws
LCD
FL cable
Mask seals LCD/FL cable M2x5 brass Glass tape
screw FL inverter board
1. Remove two mask seals at the bottom corners of the 1. Peel off the glass tape securing the FL cable.
display assembly to expose two screws securing the 2. Remove one M2x5 brass screw securing FL inverter
display mask. board.
2. Remove two M2.5x6 black screws securing the display 3. Carefully lift up the FL inverter board and disconnect
mask. the LCD/FL cable from CN1 and the FL cable
3. There are 23 latches securing the display mask. from CN2.
Carefully insert your fingers between the display mask 4. Remove four mask seals to expose four screws
and the LCD module and pry open the latches starting securing the left and right LCD brackets.
from the seven bottom latches, to the five latches on 5 Remove four M2X5 silver screws securing both
the right and left sides, ending with the six top latches. brackets.
6. Carefully rotate out the top of the LCD module
enough to access the display cable.
7. Peel off the tape securing the LCD/FL cable and
disconnect the cable.
8. Remove four M2x3 silver screws securing the left
and right LCD brackets.
TOSHIBA
Tough Enough for Today's World
FIELD REPLACEABLE UNIT DOCUMENTATION
TM
Satellite
1800 Series
14" DISPLAY MASK REMOVAL FL INVERTER AND 14" LCD REMOVAL
LCD module
Latch
M2x5.5
silver M2x5.5
screws silver
screws
Display
mask
LCD
Mask Mask
seals seals
LCD/ FL cable
FL cable
Mask seals M2x5 brass screw FL inverter board Glass tape
1. Remove two mask seals at the bottom corners of the 1. Peel off the glass tape securing the FL cable.
display assembly to expose two screws securing the 2. Remove one M2x5 brass screw securing FL inverter
display mask. board.
2. Remove two M2.5x6 black screws securing the display 3. Carefully lift up the FL inverter board and disconnect
mask. the LCD/FL cable from CN1 and the FL cable
3. There are 23 latches securing the display mask. from CN2.
Carefully insert your fingers between the display mask 4. Remove four mask seals to expose four screws
and the LCD module and pry open the latches starting securing the LCD module
from the bottom seven latches, to the five latches on 5. Remove four M2x5.5 silver screws securing the
the right LCD module.
and left sides, ending with the six top latches. 6. Carefully rotate out the top of the LCD module
enough to access the display cable.
7. Peel off the tape securing the LCD/FL cable from the
LCD module and disconnect the cable.
.
TOSHIBA
Tough Enough for Today's World
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
