Image preview - the first page of the document
toshiba_tips_141


>> Download toshiba_tips_141 documenatation <<

Text preview - extract from the document
TOSHIBA repair tips
28W23B 11AK37 SEE VESTEL.TV.html
145E7B INT DEAD LOPTX PINS
2505DBT LO HEIGHT C317(1UF50V)
2877DB C7SS COLD FIELD COLLAPSE IC301,D301, CHECK HT LEVEL
2877DB C7SS EHT SURGE/DEAD LED GREEN FLASING,FILED O/P CHIP
TA8427K
2573DB C7SR WARM TOP CRAMP 12V REGULATORLM7812
2151TB C4ER SURGE,DEAD HI HT(115VN),C817(22UF100V)
 TOSHIBA EUROPEAN SERVICE CENTRE UNITS 6/7 ADMIRALTY WAY
SOURN TRADING
 CENTRE CAMBERLY SURREY GU15 3DT, 01276 694 000.
 GOTO TOSHIBAWEBSITE

 DIM- POWER SUPPLY IS IN OVER CURRENT TRIP MODE, WITH HT AT
LESS
 THAN 20V-INCREASE C845(22UF) TO 100UF 50V.
    SETUP MODE PRESS MUTE ON HSET, PRESS AGAIN SAME TIME PUSH
MODE ON TV
 16V ADD 5K1 1/8W ACROSS D812, ON PRINT SIDE.
CHANGE C845 FROM 22 TO 100UF(50V), OR R818
Q805 IS OK QA01
Q805 IS OK N CHANGE M34300N583SP.
1 TOPTEL 001/002/003/004
1 1) IN TV MODE , SELECT CHANNEL YOU WANT TO BLOCK
1 2) SELECT BLOCK CHANNEL FUNCTION
1 3) THE INPUT THE CODE 90 (91) TO UNBLOCK
1 4) PRESS YELLOW BUTTON TO STORE CHANNEL
1 5) THE SCREEN TURNS BLACK AND CHANNEL IS BLOCKED)
1 6) PRESS CYAN BUTTON TO END;
12E4 213 PULSATING PIC WITH RAPID CHANGES IN PEAK WHITE D242
1400RB 500MA FUSE F803 IN HT LINE BLEW INT 3 RUBBER WEDGES ON
CRT CONDUCTIVE - SCAN COILS ARCING TO THEM
1400RB 500MAT F803 INT, SCAN COILS UNDER WEDGES.
1400RB 500MAT FUSE = LOPTX
1400RB AUTO TUNE NOT LOCKING ON REPLACE QA06 NO AFT ON PIN 8
ICA01 OR REPLACE QA16 NO SYNC ON PIN 9 ICA01 PTNO 233114689
1400RB FIELD COLLAPSE TA8718N.
1400RB FIELD CRAMP / STRETCHED AT TOP C303 2U2F PIN 13 IC501
JUNGLE CHIP
1400RB FIELD LIN C317(BEHIND FIELD CHIP) & C303(BEHIND IF
CAN)2U2UF RED/BROWN
1400RB FIELD LIN C317+C303 (2UF50V FUSSY) NR XTAL CPCCA00562.
1400RB LO HEIGHT/LIN R317(7R5)
1400RB ROLLING IC501 TA8718N
1400RB STR50020 POWER .
1400RB TUNING DRIFT REPLACE DA34 PTN 23115599
1400RBT FIELD COLLAPSE ,C303(2U2F50V),C317(2U2F50V)
1400RBT BOTTOM CRAMP C317(2U2F)+C303(2U2F).
1400RBT LOPTX AT2079/23=HR7604.
1400RBW FIELD COLLAPSE ,C303(2U2F50V),C317(2U2F50V)
1400RDT DEAD STR50020 U/S; DAMPER DIODE & SEVERAL RESISTORS
BUT LOPTX WAS FAULTY
1400TB CHOPPER TFMR BUZZING AFT CRT CHANGE CONNECT 330R
