TOSHIBA
MOS MEMORV PRODUCTS
DATA BOO
TOSHIBA
MOS MEMORV PRODUCTS
DATA BOOK
TABLE OF CONTENTS
Memory Selection Guide . . . . . . . . . . . . . . . . . . . . . . . . . . .. 1
Memory Cross Reference . . . . . . . . . . . . . . . . . . . . . . . . . . .. 7
Dynamic Random Access Memories. . . . . . . . . . . . . . . . . . . .. 9
TMM416P/D 16,384 Bit (16kx1) ............... 11
TMM4164C 65,536 Bit (64kx1) . . . . . . . . . . . . . . . 23
Static Random Access Memories . . . . . . . . . . . . . . . . . . . . . .. 31
TMM314AP/APL 4,096 Bit (lkx4) . . . . . . . . . . . . . . . . 33
TMM315D 4,096 Bit (4kx1) . . . . . . . . . . . . . . . . 39
TMM2016P 16,384 Bit (2kx8) . . . . . . . . . . . . . . . . 43
CMOS Static Random Access Memories . . . . . . . . . . . . . . . . . . 49
TC5501 P/D 1,024 Bit (256x4) . . . . . . . . . . . . . . . 51
TC5508P 1,024 Bit (1 kx1) . . . . . . . . . . . . . . . . 59
TC5047AP 4,096 Bit (lkx4) . . . . . . . . . . . . . . . . 65
TC5504P 4,096 Bit (4kx1) . . . . . . . . . . . . . . . . 73
TC5504AP/APL/
AD/ADL 4,096 Bit (4kx1) . . . . . . . . . . . . . . . . 79
TC5514P 4,096 Bit (1 kx4) 87
TC5514AP/APL/
AD/ADL 4,096 Bit (lkx4) . . . . . . . . . . . . . . . . 93
TC5516AP/APL 16,384 Bit (2kx8) . . . . . . . . . . . . . . . . 99
TC5517AP/APL 16,384 Bit (2kx8) . . . . . . . . . . . . . . . . 107
Mask Programmable Read Only Memories . . . . . . . . . . . . . . . . . 113
TMM334P 16,384 Bit (2kx8) . . . . . . . . . . . . . . . . 115
TMM333P 32,768 Bit (4kx8) . . . . . . . . . . . . . . . . 119
TMM2332P 32,768 Bit (4kx8) . . . . . . . . . . . . . . . . 123
TMM2364P 65,536 Bit (8kx8) . . . . . . . . . . . . . . . . 127
Erasable/Programmable Read Only Memories ............... 135
TMM323D 16,384 Bit (2kx8) . . . . . . . . . . . . . . . . 137
TMM323DI 16,384 Bit (2kx8) . . . . . . . . . . . . . . . . 143
TMM2732D 32)68 Bit (4kx8) . . . . . . . . . . . . . . . . 149
TMM2732D I 32,768 Bit (4kx8) . . . . . . . . . . . . . . . . 161
Advance Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
TC5517BP 16,384 Bit (2kx8) . . . . . . . . . . . . . . . . 171
TC5518BP 16,384 Bit (2kx8) . . . . . . . . . . . . . . . . 173
TMM2016H 16,384 Bit (2kx8) . . . . . . . . . . . . . . . . 175
TMM2764D 65,536 Bit (8kx8) . . . . . . . . . . . . . . . . 177
TMM23256P 262,144 Bit (32kx8) . . . . . . . . . . . . . . . 179
Application Note .. . . . . . . . . . . . . . . . . . . . . . . . .. . .... 181
1. Ultra Low Standby Power CMOS Memory ............. 183
2. CMOS RAM Data Retention Characteristics ............ 185
3. 16K Bit CMOS RAM Low Power Application .......... 186
4. 16K Bit Static RAM Low Power Application ........... 187
5. Advantage of Two Chip Enable Inputs in
CMOS Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 190
6. 16K RAM Interchangeability ....... : ............. 191
7. 16K Bit CMOS RAM Compatibility Table ............. 192
8. Interchangeability of CMOS RAM with NMOS RAM ...... 192
9. Byte-Wide Memory Pin-Out Table . . . . . . . . . . . . . . . . . . 194
MEMORY
SELECTION
GUIDE
-1-
