Image preview - the first page of the document



>> Download TCA-1MEG_High-Impedance_Buffer_Amplifier_System_Datasheet_60W-15629-3_2 documenatation <<

Text preview - extract from the document

High-impedance Buffer Amplifier System
TCA-1MEG Datasheet
                                                                        Applications
                                                                           Verification, Characterization, and Debug of Sophisticated Designs
                                                                           in Communications, Computer, and Semiconductor Electronic
                                                                           Environments
                                                                              Jitter and Timing Analysis (Computer Systems)
                                                                              Disk Drive Analysis
                                                                              Investigation of Transient Phenomena
                                                                              Spectral Analysis
                                                                              Power Supplies/Inverters (Switching and Linear)
                                                                              Semiconductor Devices (SCRs, IGBTs, FETs, CMOS)
                                                                              Electronic Ballasts
                                                                              Industrial/Consumer Electronics
                                                                              Mobile Communications (Phone, Satellite, Relay Stations)
                                                                              Motor Drives
                                                                              Transportation Systems (Electronic Vehicles, Electric Trains,
                                                                              Locomotives, Avionics)
Features & Benefits                                                     Tektronix award-winning TDS/CSA7000B DPO and TDS6000 Series
 Bandwidth - DC to 500 MHz                                              oscilloscopes allow engineers to make high-speed measurements quickly
                                                                        and efficiently. In addition to these high-speed measurements, many of
 Input Impedance - 1 M / 10 pF
                                                                        today's designers also face the challenges of measuring high-voltage,
 Bandwidth Limiting - Full/100 MHz/20 MHz                               current, power, or even microvolt-level signals to gain a more complete
 Input Coupling - DC/AC/GND                                             understanding of their designs.
                                                                        The TekConnect
