Image preview - the first page of the document
>> Download TM 506 parts documenatation <<
Text preview - extract from the document
TM 9-6695-244-34P
DEPARTMENT OF THE ARMY TECHNICAL MANUAL
DIRECT SUPPORT AND GENERAL SUPPORT MAINTENANCE
REPAIR PARTS AND SPECIAL TOOLS LIST
FOR
POWER MAINFRAME, TEKTRONIX MODEL TM506
(NSN 6625-01-048-8920)
Current as of 5 December 1979
Headquarters, Department of the Army, Washington, DC
4 January 1980
REPORTING OF ERRORS
You can help improve this publication by calling atten-
tion to errors and by recommending improvements and
stating your reasons for the recommendations. Your
letter or DA Form 2028, Recommended Changes to
Publications, should be mailed directly to Commander,
US Army Missile Command, ATTN: DRSMI-MFM,
Redstone Arsenal, AL 35809. A reply will be furnished
Directly to you.
Paragraph Page
SECTION I. INTRODUCTION
Scope............................................................................................................................ 1
............................. 1
General ......................................................................................................................... 2 1
Explanation of columns ................................................................................................. 3 1
Special information ....................................................................................................... 4 5
How to locate repair parts ............................................................................................. 5 5
Abbreviations ................................................................................................................ 6 6
II. REPAIR PARTS LIST ....................................................................................................................... 9
Functional Group Model Part
Group title No. No.
6691 Power Mainframe TM506 MIS30526/ITYI
III. NATIONAL STOCK NUMBER AND PART
NUMBER INDEX. ......................................................................................................... 11
i
TM 9-6695-244-34P
Section I INTRODUCTION
1. Scope. This manual lists spares and repair parts that are required for maintenance of the Power
Mainframe,
Tektronix Model TM506. It authorizes the requisitioning and issue of spares and repair parts as indicated by
the source and maintenance codes.
2. General. This repair parts and special tools list (RPSTL) is divided into the following sections:
a. Section I. Introduction.
b. Section II. Repair Parts List. A list of spares and repair parts authorized for use in the performance of
maintenance. The list also includes parts which must be removed for replacement of the authorized parts.
Parts lists are composed of functional groups in numeric sequence, with the parts in each group listed in
figure and item number sequence. Bulk materials are listed in (NSN) sequence.
c. Section III.NSN and Part Number Index. A list, in National Item Identification Number (NIIN)
sequence, of all NSN's appearing in the listings, followed by a list in alphameric sequence of all part numbers
appearing in the listings. NSN's and part numbers are cross-referenced to each illustration figure and item
number appearance.
3. Explanation of Columns
a. Illustration.This column is divided as follows:
(1) Figure Number.Indicates the figure number of the illustration on which the item is shown.
(2) Item Number. The number used to identify item called out in the illustration.
b. Source, Maintenance, and Recoverability (SMR) Codes.
(1) Source Code. Source codes indicate the manner of acquiring support items for
maintenance, repair, or overhaul of end items. Source codes are entered in the first and second
positions of the Uniform SMR Code format as follows:
Code Definition
PA - Item procured and stocked for anticipated or known usage.
PB - Item procured and stocked for insurance purpose because essentiality dictates that a minimum quantity
be available in the supply system.
PC - Item procured and stocked and which otherwise would be coded PA except that it is deteriorative in
nature.
PD - Support item, excluding support equipment, procured for initial issue or outfitting and stocked only for
subsequent or additional initial issues or outfittings. Not subjected to automatic replenishment.
PE - Support equipment procured and stocked for initial issue or outfitting to specified maintenance repair
activities.
PF - Support equipment which will not be stocked but which will be centrally procured on demand.
1
PG - Item procured and stocked to provide for sustained support for the life of the equipment.. It is applied to
an item peculiar to the equipment which, because of probable discontinuance or shutdown of production
facilities, would prove uneconomical to reproduce at a later time.
KD - An item of a depot overhaul/repair kit and not purchased separately. Depot kit defined as a kit that
provides items required at the time of over-haul or repair.
KF - An item of a maintenance kit and not purchased separately. Maintenance kit defined as a kit that
provides an item that can be replaced at organizational or intermediate levels maintenance
KB - Item included in both a depot overhaul/repair kit and a maintenance kit.
MO - Item to be manufactured or fabricated at organizational level.
MF - Item to be manufactured or fabricated at the direct support maintenance level.
MH - Item to be manufactured or fabricated at the general support maintenance level.
MD - Item to be manufactured or fabricated at the depot maintenance level.
AO - Item to be assembled at organizational level.
AF - Item to be assembled at direct support maintenance level.
AH - Item to be assembled at general support maintenance level.
AD - Item to be assembled at depot maintenance level.
XA - Item is not procured or stocked because the requirements for the item will result in the replacement of
the next higher assembly.
XB - Item is not procured or stocked. If not available through salvage, requisition.
XC - Installation drawing, diagram, instruction sheet, field service drawing, that is identified by manufacturer's
part number.
XD - A support item that is not stocked. When required, item will be procured through normal supply
channels.
NOTE Cannibalization or salvage may be used as a source of supply for any items coded above except
those coded XA and aircraft support items as restricted by AR 700-42.
(2) Maintenance Code. Maintenance codes are assigned to indicate the levels of maintenance
authorized to USE and REPAIR support items. The maintenance codes are entered in the
third and fourth positions of the Uniform SMR Code format as follows:
(a) The maintenance code entered in the third position will indicate the lowest maintenance level
authorized to remove, replace, and use the support item. The maintenance code entered in
the third position will indicate one of the following levels of maintenance:
2
Code Application/Explanation
C - Crew or operator maintenance performed within organizational maintenance.
O - Support item is removed, replaced, used at the organizational level.
F- Support item is removed, replaced, used at the direct support level.
H - Support item is removed, replaced, used at the general support level.
D - Support items that are removed replaced, used at depot, mobile depot, or specialized repair activity only.
(b) The maintenance code entered in the fourth position indicates whether the item is to be repaired and
identifies the lowest maintenance level with the capability to perform complete repair (i.e., all authorized
maintenance functions). This position will contain one of the following maintenance codes:
Code Application/Explanation
O - The lowest maintenance level capable of complete repair of the support item is the organizational level.
F - The lowest maintenance level capable of complete repair of the support level.
H - The lowest maintenance level capable of complete repair of the support item is the general support level.
D - The lowest maintenance level capable of complete repair of the support item is the depot level.
L - Repair restricted to (enter applicable designated specialized repair activity),
Z - Nonreparable. No repair is authorized.
B - No repair is authorized. The item may be reconditioned by adjusting, lubricating, etc., at the user level. No
parts or special tools are procured for the maintenance of this item.
(3) Recoverability Code. Reactivity codes are assigned to support items to indicate the disposition
action on unserviceable items. The recoverability code is entered in the fifth position of the Uniform SMR
Code format as follows:
Recoverability Codes Definition
Z - Nonreparable item. When unserviceable, condemn and dispose at the level indicated in position 3.
O - Reparable item. When uneconomically reparable, condemn and dispose at organizational level.
F - Reparable item. When uneconomically reparable, condemn and dispose at the direct support level.
3
H. - Reparable item. When uneconomically reparable, condemn and dispose at the general support level.
D - Reparable item. When beyond lower level repair capability, return to depot. Condemnation and disposal
not authorized below depot level.
L - Reparable item. Repair, condemnation, and disposal not authorized below depot/specialized repair
activity level.
A - Item requires special handling or condemnation procedures because of specific reasons (i.e., precious
metal content, high dollar value, critical material or hazardous material). Refer to appropriate
manuals/directives for specific instructions.
c. National Stock Number (NSN). Indicates the NSN assigned to the item and which will be used for
requisitioning.
d. Part Number. Indicates the primary number used by the manufacturer (individual, company, firm,
corporation, or Government activity), which controls the design and characteristics of the item by means of
its engineering drawings, specifications, standards, and inspection requirements to identify an item or range of
items.
NOTE
When a stock numbered item is requisitioned, the item received may have a different part number than the
part being replaced.
e. Federal Supply Code for Manufacturer (FSCM). The FSCM is a 5-digit numeric code listed in SB 708-42
which is used to identify the manufacturer, distributor, or Government agency, etc.
f. Description. Indicates the Federal item name and, if required, a minimum description to identify the
item. The physical security classification of the item is indicated by the parenthetical entry (insert applicable
physical security classification abbreviation, e.g., Phy Sec Cl (C)-Confidential, Phy Sec C1 (S)-Secret, Phy
Sec Cl (T)-Top Secret). Items that are included in kits and sets are listed below the name of the kit or set with
the quantity of each item in the kit or set indicated in the quantity incorporated in unit column. When the part
to be used differs between serial numbers of the same model, the effective serial numbers are shown as the
last line of the description. In the Special Tools List, the initial basis of issue (BOI) appears as the last line in
the entry for each special tool, special Test, Measurement, and Diagnostic Equipment (TMDE), and other
special support equipment. When density of equipments supported exceeds density spread indicated in the
BOI, the total authorization is increased accordingly.
g. Unit of Measure (U/M). Indicates the standard of the basic quantity of the listed item as used in
performing the actual maintenance function. This measure is expressed by a two-character alphabetical
abbreviation (e.g., ea, in, pr, etc). When the unit of measure differs from the unit of issue, the lowest unit of
issue that will satisfy the required units of measure will be requisitioned.
4
h. Quantity Incorporated in Unit. Indicates the quantity of the item used in the breakout shown on the
illustration figure, which is prepared for functional group, subfunctional group, or an assembly. A "V"
appearing in this column in lieu of quantity indicates that no specific quantity is applicable (e.g., shims,
spacers, etc).
4. Special information
a. Repair parts for components of standards sets which can be identified as existing in the supply
system will be requisitioned through normal supply channels from the appropriate supply commodity
manager.
b. Repair parts for components of standards sets which cannot be identified as to proper supply
source will be requisitioned from USAMICOM, using routing identifier B64 and furnishing as a minimum, the
following as exception data.
(1) Component stock number of the individual end item to be repaired.
(2) Component manufacturer's equipment model number and serial number.
(3) The equipment manufacturer's stock number as listed in the appropriate manual for the
desired repair part.
(4) The repair part reference designation, circuit reference, circuit symbol schematic
designation, or reference number as listed in the manufacturer's manual.
(5) The technical specification of the repair part as contained in the appropriate
manufacturer's manual.
(6) The title and date of the manufacturer's manual from which the information in paragraphs
a, b(3), (4), and (5) above was taken.
NOTE
Repair parts should not be requisitioned for plug-in boards identified in the plug-in boards identified in the
plug-in board exchange program, except by the depot designated to perform the repair. Repair of
calibration set components, with plug-in board assemblies or subassemblies designated as program
exchange replacements with a recoverability code of L, will be accomplished by replacing the plug-in board.
c. The plug-in board exchange program functions are as follows:
(1) Requisitioning instructions for initial issue plug-in boards will be provided since new
instrument boards are included in the program.
(2) As a plug-in board covered by the program fails, a replacement will be requisitioned.
Requisitions will be submitted to Commander, US Army Missile Command, B64, Redstone Arsenal,
AL 35809.
(3) Simultaneously with c(2) above, the defective board being replaced will be shipped by
certified mail, return receipt requested, to the following address:
Transportation Officer
Anniston Army Depot
M/F Field Service Stock
Anniston, AL 36201
When requisitioning a replacement board, the turn-in document number of the replaced board shall be cited
on requisition.
5. How to Locate Repair Parts
a. When NSN or reference number is unknown:
(1) First. Using the table of contents, determine the assembly (functional group) within
which the repair part belongs.
5
(2) Second. Using the repair parts listing, find the functional group to which the repair part
belongs and locate the item by description.
b. When NSN or reference is known:
(1) First. Using the index of NSN's and reference numbers, find the pertinent NSN or
reference number. This index is in ascending NSN cross-referenced to the illustration figure number and item
number.
(2) Second. Using the repair parts listing, find the figure and item number, and locate the figure
and item number in the repair parts list.
6. Abbreviations.The abbreviations listed below may appear in this RPSTL:
AC ------------ alternating current ELEC--------- electrical
ACC -------- accordance EQUIPM------- equipment
ACCUR ------ accuracy F--------------- Fahrenheit
AL----------- aluminum FED----------- Federal
AMP ---------- ampere FIN------------- finish
ASSY -------- assembly
ASTM -------- American Standard
or Testing Materiel FLG ----------- flange
ATTEN ------- attenuation FREQ--------- frequency
AWG ---------- American Wire Gage FSCM---------- Federal supply code
for manufacturer
BAN----------- banana FT-------------- foot
BLK------------ black GC----------- gigacycles
BR------------- brass
C-------------- centigrade, calibration, cycles second GEN ---------- generator
CAL ------------ calibrate GHZ ---------- gigahertz
CAP--------- capacitance GPM ---------- gallons per minute
CD ----------- code GPM ---------- gallons per minute
CER ----------- ceramic GRAD -------- graduation
COAX ------- coaxial H ------------- high
COMP--------- composition HD------------ head
CONDM--------- conductor HYDR -------- hydraulic
CONN ---------- connector HZ----------- hertz
CONS--------- consisting ID ------------- inside diameter
CONT-------- continual IN--------- inch
COP ---------- copper INCL - ---------- inclusive
COR ---------- corrosion K ------------- thousand (prefix)
CPS ---------- cycles per second KC----------- kilocycles
CU ------------- cubic KG----------- kilograms
CUR ---------- current KHZ ---------- kilohertz
CYL ---------- cylinder KMHZ -------- thousand megahertz
DB ------------- decibel KV------------ kilovolts
DBL---------- double LAB ----------- laboratory
DC ------------ direct current LB---------- pounds
DEG ------------ degree LG------------ length
DET ---------- detector LT---------- light
DIA ----------- diameter
DIM ------------- dimension
DIV------------ division
DPDT --------- double pole double throw
DPL------------ deployment
6
M ---------------thousand RPM------------ revolutions per
minute
MA ---------- milliampere S ------------- single
MAX ----------maximum SEC---------- seconds
MC ---------- megacycles SECT ---------- section
MFD --------- millifarads SERR-------- serrated
MFR ----------manufacturer SHK ---------- shank
MG ---------- milligrams SNG ---------- single
MHZ ----------megahertz SPEC ---------- specification
MIN ---------- minimum, minutes SPL ---------- special
ML ---------- milliliters SQ -------------- square
MM ---------- millimeters STD------------ standard
MOD ----------modified STGT---------- straight
MSEC ---------milliseconds SW ----------- switch
MTL ----------material SWR ---------- standing
wave ratio
MV ---------- millivolts SYS ---------- system
MW---------- milliwatts TEL ---------- telescopic
NBS---------- National Bureau Standards TERM --------- terminal
NEG --------- negative THD---------- thread
NO-------------number THERM ------- thermometer
NOM--------- nominal THK ---------- thick
NPT --------- National Pipe Thread TSTR --------- tester
NSN --------- National stock number U ----------- unit
OA ------------overall UF ---------- microfarads
OD ----------- outside diameter UHF------ ultra high
frequency
OPER --------operating V ------------ volts
OZ ----------- ounce VAC ---------- volts alternating
current, vacuum
PCS --------- pieces VDC ---------- volts direct current
PCT ----------percent VHF ---------- very high frequency
PF ------------picofarads VSWR --------- voltage standing
wave ratio
PK ----------- peck W ------------ watts, with, width
PLTD ------- plated WT ---------- weight
PN ----------- part number
POS----------positive
PP ---------- peak-to-peak
PSI ---------- pounds per square inch
PWR--------- power
REF---------- reference
REP--------- repetition
REQ -------- required
REQMTS----requirements
RES---------- resistance
RF ----------- radio frequency
RG ---------- range
RH ----------- right hand
RL------------ reel
RM ----------- rack mounted
RMS ---------root mean square
ROT ----------rotating
7 (8 BLANK)
SECTION II. REPAIR PART LIST
(1) (2) (4) (5) (6) (7) (8)
(3)
ILLUSTRATION QTY
NATIONAL DESCRIPTION INC
(a) (b) SMR
STOCK PART IN
FIG ITEM CODE U/M UNIT
NUMBER NUMBER FSCM USABLE ON CODE
NO. NO.
GROUP 6691
MAINFRAME, POWER MOD
TM506 80009
MSI30526/1TY1 18876
1 10 PAFZZ 5340-00-062-5431 348 0191-00 80009 UMPER.PLASTIC EA 1
1 20 PAFZZ 6225-01-018-2369 161-0033-04 80009 CABLE ASSEMBLY POWER EA 1
1 30 PAFZZ 5910-00-546-3271 283-0024-00 80009 CAPACITOR,FIXFED EA 1
1 40 PAFZZ 5910-00-577-1346 DA49-001CB 71590 CAPACITOR,FIXEC,CER EA 16
1 50 PAFZZ 5910-01-022-3075 290-0637-00 80009 CAPACITOR.FIXEC,ELE EA 4
1 60 PAFZZ 5910-00-467-1548 80D10444 56286 CAPACITOR,FIXEC.ELE EA 3
1 70 PAFZZ 6695-01-084-9120 70-3303-00 80009 CIRCUIT CARD ASSY EA 1
1 80 PAFZZ 6695-01-084-9121 670-3984-00 80009 CIRCUIT CARD ASSY EA 1
1 90 PAFZZ 6695-01-084-9122 670-3834-00 80009 CIRCUIT CARD ASSY EA 1
1 100 PAFZZ 5999-00-465-9987 344-0154-00 80009 CLIP.,ELECTRICL EA 16
1 110 PAFZZ 5999-00-551-9433 131-0608-00 80009 CONTACT,ELECTRICAL EA 16
1 120 PAFZZ 5999-00-396-6331 131-0707-00 80009 CCNTACT.ELECTRICAL EA 6
1 130 PAFZZ 5935-00-599-8548 131-1078-00 80009 CONNECTOR.RECEPTACEL EA 6
1 140 PAFZZ 5935-00-599-8548 131-1078-00 80009 CCNNECTOR, RECEPTACLE EA 6
1 150 PAFZZ 4140-00-726-9755 WR2A1 82877 FAN,TUBEAXIAL EA 1
1 160 PAFZZ 4140-00-726-9755 WR2A1 82877 FAN,TUBEAXIAL EA 1
1 170 PAFZZ 4140-00-113-0989 NU2A1 82877 FAN,VENTILATING EA 1
1 180 PAFZZ 4130-00-281-4034 378-0029-00 80009 FILTER MEDIA,AIR EA 1
1 190 PAFZ 5920-00-807-8659 159-0023-00 80009 FUSE,CARTRIDGE EA 2
1 200 PAFZZ 5920-00-082-7561 159-0027-00 80009 FUSE,CARTRIDGE EA 1
1 210 PAFZZ 5920-00-284-7466 10328857 18876 FUSE,CARTRIDGE EA 1
1 220 PAFZZ 5920-00-284-7079 AGC2-1/2 71400 FUSE,CAPTRIDGE. EA 2
1 230 PAFZZ 5920-00-056-6620 AGC7-1-2 71400 FUSE,CARTRIDGE EA 1
1 240 PAFZZ 5920-00-728-6767 59A5A260-3 10001 FUSE,ELECTRICAL EA 1
1 260 PAFZZ 5920-01-005-9621 382-0362-00 80009 FUSEHOLDER, EXTRACTOR EA 1
1 270 PAFZZ 4140-30-227-8228 20132-2 82877 GUARO,MECHANICAL DRIVE EA 1
1 280 PAFZZ 5340-01-056-2929 251-0286-04 80009 GUIDE EA 1
1 290 PAFZZ 5340-01-056-2930 351-0379-01 80009 GUIDE EA I
1 300 PAPFZZ 5970-00-571-8317 166-0434-00 80009 INSULATOR,BUSFING EA 4
1 310 PAFZZ 5970000-451-0436 210-0935-00 80009 INSULATOR,BUSING EA 2
1 320 PAFZZ 5970-01-024-4788 342-0136-00 80009 INSULATORWASER EA 10
1 330 PAFZZ 5970-00-491-0108 386-0978-00 80009 INSULATOR,PLATE. EA 1
1 340 PAFZZ 5935-00-488-3412 214-1593-02 80009 KEY,POLAPIZING,ELEC EA 6
1 350 PAFZZ 5310-00-00h-8205 210-0458-00 80009 NUT, PLAIN,HEXAGON EA 4
9
(1)
(6) (7) (8)
ILLUSTRATION (2) (3) (4) (5)
QTY
(a) (b) NATIONAL DESCRIPTION INC
FIG ITEM SMR STOCK PART IN
NO. NO. CODE NUMBER NUMBER FSCM USABLE ON CODE U/M UNIT
1 360 PAFZZ 5310-00-655-6534 40T10 52983 NUT,PLAIN ASSEMBLED EA 4
1 370 PAFZZ 5310-00-845-7736 NAS671B6 80205 NUT,PLAIN,HEXAGCN
. EA 2
1 380 PAFZZ 5310-00-836-3520 511-041800-00 78189 NUT,PLAIN,ASSEMBLED EA 2
1 390 PAFZZ 5310-00-841-8106 210-0457-00 80009 NUT,,PLAIN,HEXAGON EA 7
1 400 PAFZZ 5905-01-014-4756 308-0734-00 80009 RESISTOR,FIXED,FILM EA 1
1 410 PAFZZ 5905-00-138-4927 RCR42G102JS 81349 RESISTOR, FIXED,COMP EA 3
1 420 PAFZZ 5905-30-11C-0992 RCR32G511JS 81349 RFSISTORFIXEO,COMP EA 2
1 430 PAFZZ 5305-30-20e-2733 SC10094 80249 SCREW,ASSEMBLED WASHER EA 12
1 440 PAFZZ 5305-00-316-9526 212-0082-00 80009 SCEW EA I
1 450 PAFZZ 5305-00-492-2145 211-0101-00 80009 SCREW,MACHINE EA 1
1 460 PAFZZ 53C5-00-625-9546 212-0040-00 80009 SCREW,,MACHINE EA 32
1 470 PAFZZ 5305-00-989-3116 MS35206-213 96906 SCREW,MACHINE EA 2
1 480 PAFZZ 5305-01-006-8957 211-0012-00 83385 SCREW,MACHINE EA 3
1 490 PAFZZ 5305-00-418-8251 211-0097-00 80009 SCREW,MACHIINE EA 1
1 500 PAFZZ 5305-01-077-0167 212-0511-00 80009 SCPEW.CAP.HEXAGON HEAD EA 4
1 510 PAFZZ 5305-00-40e-0129 8186861 18876 SCREWW,MACHINE EA 2
1 520 PAFZZ 53C5-30-63e-0502 MS35214-28 96906 SCREW,MACHINE EA 1
1 530 PAFZZ 53C5-00-005-0795 211-0507-00 80009 SCREW,MACHINE EA 8
1 540 PAFZZ 5305-00-763-7822 MS51959-14 96906 SCREW,MACHINE EA 5
1 540 PAFZZ 5305-00-889-3000 MS35206-230
1 560 PAFZZ 5305-00-841-8060 211-0105-00 80009 SCREW,MACHINE EA 1I
1 570 PAFZZ 5961-00-92C-4975 IN4721 80131 SEMICONDUCTOR DEVICE EA 4
1 580 PAFZZ 5961-00-131-1197 152-0274-30 80009 SEMICONDUCTOR DEVICE EA 4
1 590 PAFZZ 15030-00-829 3251 SE1156363 81439 SW!TCH,ELECTRICAL EA 2
1 600 PAFZZ 5930-00-344-2011 2DM301 91929 SWITCH.PUSH-PULL EA 1
1 610 PAFZZ 5030-00-344-2011 2DM301 91929 SWITCH,PUSH-ULL EA 1
1 620 PAFZZ 5930-00-829-3251 SE11S6363 81439 SWITCH,E,LECTRIC .EA 2
1 630 PAFZZ 5961-00-370-1271 151-0373-00 80009 TRANSISTOR EA 5
1 650 PAFZZ 5961-01-033-3079 MJ2955 04713 TRANSISTOR EA 1
1 660 PAFZZ 5'61-00-724-2131 151-0140-00 80009 TRANSISTOR EA 1
1 670 PAFZZ 5940-00-827-2653 MS77068-2 96906 TERMINAL,LUG EA 1
1 680 PAFZZ 5943-00-156-7344 FRYE20 05624 TERMINAL,LUG EA 1
1 690 PAFZZ 5940-00-271-4622 1510 71785 TERMINAL BOARD EA 1
1 700 PAFZZ 5940-00-682-2477 MS77068-1 96906 TERMINAL,LUG EA 1
1 710 PAFZZ 5310-00-192-0631 210-0873-00 80009 WASHER,FLAT EA 1
1 720 PAFZZ 5310-01-031-7134 213-0804-03 80009 WASHER,FLAT EA 6
1 730 PAFZZ 5310-C0-113-1494 210-0851-00 80009 WA5HER,FLAT EA 1
1 740 PAFZZ 5310-01-064-7816 210-0055-00 80009 WASHER,LOC EA 4
1 750 PAFZZ 5310-03-418-2621 210-0802-00 80009 WASHER,LOCK EA 2
10
SECTION III NATIONAL STOCK NUMBER AND PART NUMBER INDEX
FIGURE ITEM FIGURE ITEM
STOCK NUMBER NO. NO. STOCK NUMBER NO. NO.
5305-00-0C5-C795 1 530 5935-00-599-8548 1 140
5310-00-006-8205 1 350 5305-00-625-9546 1 460
5920-00-056-6620 1 230 5305-00-638-0502 1 523
5340-00-062-5431 1 10 5310-00-655-6534 1 360
5920-00-082-7561 1 200 5940-00-682-2477 1 703
5905-00-110-C992 1 420 5961-00-724-2138 1 660
4140-00-113-C989 1 170 4140-03-726-9755 1 150
5310-00-113-1494 1 73C 414C-00-726-9755 1 160
5961-00-131-1197 1 580 5920-00-728-6767 1 240
5905-00-138-4927 1 410 5305-00-763-7822 1 540
5940-00-156-7344 1 680 592C-00-807-8659 1 190
5310-00-192-0631 1 710 5940-00-827-2653 1 670
5305-00-206-2733 1 430 593C-30-829-3251 1 590
4140-00-227-8228 1 27C 5930-30-829-3251 1 620
5940-00-271-4622 1 690 5310-00-836-3520 1 380
4130-00-281-4034 1 180 53C5-00-841-806C 1 560
5920-00-284-7C79 1 220 5313-00-841-8106 1 390
5920-00-284-7466 1 210 5310-00-845-7736 1 370
5305-00-316- 526 1 440 5305-30-889-3000 1 550
5930-00-344-2011 1 60C 5305-00-889-3116 1 470
5930-00-344-2011 1 610 5961-00-929-4975 1 570
5961-00-370-1271 I 630 592}-01-005-9621 1 260
5999-00-396-t331 1 120 53305-31-306-8957 1 480
5305-00-408-0129 1 510 5905-01-314-4756 1 400
5310-00-418e-2621 1 750 6625-01-018-2369 1 20
5305-00-418-8251 1 490 5910-01-022-3075 1 53
5970-00-451-0436 1 310 5970-01-024-4788 1 320
5999-00-4t5-S987 1 100 5310-01-331-7134 1 720
5910-00-467-1548 1 60 5961-01-033-3079 1 650
5935-00-488-3412 1 340 5340-31-056-2929 1 280
5970-00-491-0108 1 330 5340-01-056-2930 1 290
5305-00-492-2145 1 450 5310-01-364-7816 1 740
5910-00-546-3271 1 30 5305-01-077-0167 1 500
5999-00-551-9433 I 110 6695-31-084-9120 1 73
5970-00-571-8317 1 300 6695-01-084-0121 1 83
5910-00-577-1346 1 40 6695-01-084-9122 1 90
5935-00-599-8548 1 13C
FIG. ITEM PART FIG. ITEM
FSCM NO. NO. NUMBER FSCM NO. NO.
AGC2-1/2 71400 1 220 210-0055-00 80009 1 740
AGC7-1-2 71400 1 230 210-0457-00 80000 1 390
0A149-001CB 71590 1 40 210-0458-00 80009 1 350
FRYE20 05624 1 680 210-0802-00 80009 1 750
MJ2955 04713 1 650 210-0804-00 80009 1 720
MS35206-213 96906 1 470 210-0851-00 80009 1 730
MS35206-230 96906 1 550 210-0873-CO 80009 1 710
MS35214-28 96906 1 520 210-0935-00 80009 1 310
MS51959-14 96906 1 540 211-0012-00 83385 1 480
MS77068-1 96906 1 700 211-0097-00 80009 1 490
M577068-2 96906 1 670 211-0101-03 80009 1 450
MU2A1 82877 1 170 211-0105-00 80009 1 560
NAS67186 80205 1 370 211-0507-30 80009 1 533
RCR325GS11JS 81349 1 420 212-004-00 80009 1 460
RCR42G1O2JS 81349 1 410 212-0082-00 80009 1 440
SC10094 80249 1 430 212-0511-00 80009 1 503
SE11S6363 81439 1 590 214-1593-02 80009 1 340
SEll156363 81439 1 620 283-0024-00 80009 1 30
WR2A1 82877 1 150 290-0637-00 80009 1 50
W2AI 82877 1 160 308-0704-03 80009 1 400
1N4721 80131 1 570 342-0136-30 80309 1 320
10328857 18876 1 210 344-0154-00 80009 1 100
131-0608-00 80009 1 110 348-0191-00 80009 1 13
131-0707-C0 80009 1 120 351-028604 80009 1 283
131-1078-00 80009 1 130 351-0379-01 80009 1 293
131-1078-00 80009 1 140 352-0362-00 80039 1 263
151-0140-00 80009 1 660 378-0029-30 80009 1 180
151-0373-00 80009 1 630 386-0978-00 80009 1 330
1510 71785 1 690 40710 52983 1 360
152-0274-00 80009 1 580 511-041800-30 78189 1 380
159-0023-00 80009 1 190 59A5A260-3 10031 1 240
159-0027-C0 80009 1 200 670-3303-00 80009 1 70
161-0033-04 80009 1 20 670-3834-00 80009 1 90
166-0434-00 80009 1 300 670-3984-00 80009 1 83
20M301 91929 1 600 68010444 56289 1 60
20M301 91929 1 610 8186861 18876 1 510
20132-2 82877 1 270
11
By Order of the Secretary of the Army:
E. C. MEYER
General, United Sta
tes
Army
Official: Chief of Staff
J. C. PENNINGTON
Major General, United States Army
The AdjutantGeneral
Distribution:
To be distributed in accordance with DA Form 12-34A, requirements for Calibration Procedures
Publications
*U.S. GOVERNMENT PRINTING OFFICE: 1980-640217/311
◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
