Image preview - the first page of the document
>> Download WD AV-GP II documenatation <<
Text preview - extract from the document
WD AV-GP
Power-saving Hard Drives
Power-conserving WD AV-GP SATA hard drives take
advantage of WD GreenPower TechnologyTM to meet the
24x7 requirements of demanding audio and video
environments. With power reduction of up to 40 percent,
they deliver cool and quiet operation and reliability perfect
for audio video applications such as PVRs, DVRs, set-top
boxes (STBs) as well as surveillance video recording.
INTERFACE WIDTH/HEIGHT ROTATIONAL SPEED CAPACITIES
SATA 3 Gb/s 3.5-inch/1-inch IntelliPower 160 GB to 2 TB
MODEL NUMBERS
WD20EURS WD10EURS WD7500AVDS WD2500AVVS Note: Not all products may
WD20EVDS WD10EVDS WD5000AVDS WD1600AVVS be available in all regions of
WD15EURS WD10EVVS WD5000AVVS the world.
WD15EVDS WD7500AURS WD3200AVVS
Product Features
24x7 reliability SilkStreamTM IntelliParkTM Advanced Format (AF)
These drives are designed to last in Optimized for smooth, continuous Parks the recording heads off the Technology being adopted by WD
always-on, streaming digital audio/ digital video playback of up to disk surface during spin up, spin and other drive manufacturers as
video environments such as twelve simultaneous HD streams. down, and when the drive is off. one of multiple ways to continue
PVR/DVR, DVR recorders, and SilkStream is compatible with the This ensures the recording head growing hard drive capacities. AF is
surveillance video recorders. ATA streaming command set so CE never touches the disk surface a more efficient media format that
customers can use standard resulting in improved long term enables increased areal densities.
streaming management and error reliability due to less head wear, and (EURS/AURS models only)
Reduced power recovery options. improved non-operational shock
consumption tolerance.
1 million hours MTBF
With the combination of WD's IntelliSeekTM
IntelliSeek, IntelliPark, and Best-in-class reliability for
Calculates optimum seek speeds to
Preemptive Wear Leveling mainstream 3.5-inch form-factor AV
IntelliPower technologies, WD has
reduced power consumption by up lower power consumption, noise, (PWL) storage.**
to 40 percent compared to and vibration. The drive arm frequently sweeps
competitors' drives. Lower power across the disk to reduce uneven * A sone is a subjective unit of loudness as perceived by a
means less heat and better wear on the drive surface common person with normal hearing.
IntelliPowerTM ** Based upon dual tuner system operating in typical 30◦ Jabse Service Manual Search 2024 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
