Image preview - the first page of the document
>> Download WD RE3 (32 MB Cache) II documenatation <<
Text preview - extract from the document
WD RE3
Enterprise Hard Drives
Enterprise Hard Drives
High Performance
24x7 Reliability
1.2 Million Hours MTBF
Interface WD RE3 7200 RPM Enterprise SATA hard drives are packed with
performance and reliability features making them the perfect solution for
SATA servers, video surveillance, and other demanding write-intensive applications.
With a designed, manufactured and demonstrated MTBF of 1.2 million hours
at 100% duty cycle in nominal enterprise conditions, up to 32 MB cache, and
Width/Height best-in-class vibration tolerance, these drives are the ultimate in Enterprise
SATA storage.
3.5-inch/1-inch
Product Benefits
Massive capacity - WD RE3 Enterprise SATA drives are available in capacities up to 1 TB.
Rotational Speed
Dual processor - Twice the processing power delivers best-in-class performance for
demanding Enterprise applications.
7200 RPM
RAFFTM - Our fourth generation RAFF technology includes sophisticated electronics to
monitor the drive and correct both linear and rotational vibration for up to a 60% performance
improvement in high vibration environments over the previous generation of drives.
Capacities
IntelliSeekTM - Calculates optimum seek speeds to lower power consumption, noise, and
vibration in active seek modes without degrading performance.
250 GB to 1 TB StableTracTM - The motor shaft is secured at both ends to reduce system-induced vibration
and stabilize platters for accurate tracking during read and write operations. (750 GB and
above)
Model Numbers Multi-axis shock sensor - Automatically detects the subtlest shock events and
compensates to protect the data.
WD1002FBYS RAID-specific, time-limited error recovery (TLER) - Prevents drive fallout caused by the
WD7502ABYS extended hard drive error-recovery processes common to desktop drives.
WD5002ABYS
Third generation dynamic fly height - Each read-write head's fly height is adjusted in real
WD3202ABYS time for optimum reliability.
WD2502ABYS
Thermal extended burn-in test - Each drive is put through extended burn-in testing with
thermal cycling to ensure reliable operation.
NoTouchTM ramp load technology - The recording head never touches the disk media
ensuring significantly less wear to the recording head and media as well as better drive
Note: Not all products protection in transit.
may be available in all Perpendicular Magnetic Recording (PMR) - WD RE3 Enterprise SATA drives utilize PMR
regions of the world. technology to achieve even greater areal density, reliability, and design margin.
5-year limited warranty
Applications
Ideal for servers, storage arrays, video surveillance, and other demanding applications.
The WD Promise
ES MORE T
WD understands the importance of the information you save to your hard
DO
drive and we are committed to protecting that data with exceptionally reliable
O
NO ONE
products, advanced data protection technology, and superior customer support.
D ATA
No one does more to safeguard your data than WD.
UR
SA
FEG YO
UARD
WD RE3
Enterprise Hard Drives
Enterprise Hard Drives
Specifications 1
1 TB 750 GB 500 GB 320 GB 250 GB
Model number WD1002FBYS WD7502ABYS WD5002ABYS WD3202ABYS WD2502ABYS
Interface SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s SATA 3 Gb/s
Formatted capacity 1,000,204 MB 750,156 MB 500,107 MB 320,072 MB 251,059 MB
User sectors per drive 1,953,525,168 1,465,149,168 976,773,168 625,142,448 490,350,672
Native command queuing Yes Yes Yes Yes Yes
SATA latching connector Yes Yes Yes Yes Yes
Actuator latch/auto park Yes Yes Yes Yes Yes
Form factor 3.5-inch 3.5-inch 3.5-inch 3.5-inch 3.5-inch
RoHS compliant2 Yes Yes Yes Yes Yes
Performance
Data transfer rate (max)
Buffer to host 3 Gb/s 3 Gb/s 3 Gb/s 3 Gb/s 3 Gb/s
Host to/from drive (sustained) 113 MB/s 113 MB/s 113 MB/s 118 MB/s 118 MB/s
Cache (MB) 32 32 16 16 16
Average latency (ms) 4.2 4.2 4.2 4.2 4.2
Rotational speed (RPM) 7200 7200 7200 7200 7200
Average drive ready time (sec) 17 17 11 6.5 6.5
Configuration/Organization
Heads/disks 6/3 5/3 4/2 2/1 2/1
Bytes per sector (STD) 512 512 512 512 512
Reliability/Data Integrity
Load/unload cycles3 300,000 300,000 300,000 300,000 300,000
Non-recoverable read errors per bits read <1 in 1015 <1 in 1015 <1 in 1015 <1 in 1015 <1 in 1015
Limited warranty (years)4 5 5 5 5 5
Power Management
12VDC (A, max) 2.1 2.1 2.1 2.1 2.1
Average power requirements (W)
Read/Write 8.0 8.0 7.1 5.5 5.5
Idle 7.2 7.2 6.6 5.1 5.1
Standby 0.85 0.85 0.85 0.85 0.85
Sleep 0.85 0.85 0.85 0.85 0.85
Environmental Specifications5
