RX-A3010/RX-V3071
AMP 1/2
1
AMP (1)
CENTER
For service
CB105 W1518A Page 141 E9
to AMP (3)_W1518B
2 CB111
Page 142 D10
to AMPPOWER (1)_W1809
Page 132 J9 Page 132 I9
to DIGITAL1 (1)_CB93 IC100 IC102
to DIGITAL1 (1)_CB84
IC101 IC103
W1001
W1002
AMP (4) AMP (5) F. PRESENCE L
3
CB113
Page 137 H9 For service
AMP (2) to FUNCTION (1)_W708
CB106 W1519A Page 141 D9
to AMP (3)_W1519B
For service
CB101
W1512A Page 141 D9
4 to AMP (3)_W1512B
W1517A Page 141 J9
to AMP (3)_W1517B
SURROUND L
For service
5 CB107 W1521A Page 141 L9
to AMP (3)_W1521B
For service
CB102
W1513A Page 141 L9
Page 142 D10
to AMP (3)_W1513B
to AMPPOWER (1)_W1808A
6 Page 142 D10
to AMPPOWER (1)_W1808B
FRONT L
Page 142 E10
to AMPPOWER (1)_W1807A
Page 142 E10 For service
to AMPPOWER (1)_W1807B
CB108 W1520A Page 141 G9
to AMP (3)_W1520B
7
For service
CB103
W1514A Page 141 F9
to AMP (3)_W1514B
SURROUND BACK L
8
For service
Page 141 K9
CB109
W1522A
to AMP (3)_W1522B
Page 137 H9 For service
CB104 W1516A Page 141 J9
to FUNCTION (1)_W709
9 to AMP (3)_W1516B
CB112 W1515A
Page 141 K9
to AMP (3)_W1515B
W1005
Page 142 B2
W1003 to AMPPOWER (1)_CB180
Page 142 B1
to AMPPOWER (1)_CB181
10
Components having special characteristics are marked and must be replaced
with parts having specifications equal to those originally installed.
Schematic diagram is subject to change without notice.
140
A B C D E F G H I J K L M N
RX-A3010/RX-V3071
AMP 2/2
1
2
SPEAKERS
AMP (3)
3 CENTER FRONT ZONE2/ZONE3/R. PRESENCE SURROUND BACK SURROUND
L/R L/R L/R L/R
W1526A
4
5
6
R. PRESENCE L
7
F. PRESENCE L
8
CENTER
FRONT L SURROUND BACK L
SURROUND L
W1521B
W1516B
W1517B
9
W1515B
W1522B
W1513B
W1512B
W1519B
W1518B
W1514B
W1520B
W1526B
W1523
W1525
CB114
CB110
Page 142 H3 Page 142 I3
to AMPPOWER (1)_W1810 Page 140 G4 to AMPPOWER (2)_CB194 Page 140 G7 Page 140 N4 Page 140 G9 Page 140 G6
(for service)
to AMP (2)_W1512A to AMP (2)_W1514A to AMP (2)_W1517A to AMP (2)_W1515A to AMP (2)_W1513A
Page 140 N3 Page 140 N2 Page 140 N7 Page 140 G9 Page 140 N8 Page 140 N7
to AMP (1)_W1519A to AMP (1)_W1518A to AMP (1)_W1520A to AMP (1)_W1516A to AMP (1)_W1522A to AMP (1)_W1521A
10 Page 142 E10
to AMPPOWER (1)_1803A, W1803B
Components having special characteristics are marked and must be replaced
with parts having specifications equal to those originally installed.
Schematic diagram is subject to change without notice.
141
