Image preview - the first page of the document
>> Download RXA3010_PRECAUTIONS documenatation <<
Text preview - extract from the document
RX-A3010/RX-V3071
INTERNAL VIEW
RX-A3010/RX-V3071
Rear view 1 2
1 VIDEO (1) P.C.B.
2 AMPPOWER (3) P.C.B. (R model)
3 AMPPOWER (2) P.C.B.
4 AMP (3) P.C.B.
5 HD RADIO TUNER (U model)
AM/FM TUNER (C, R, T, K, A, B, G, F, L, J models)
6 FUNCTION (2) P.C.B.
7 6 5 4 3 7 FUNCTION (1) P.C.B.
Top view
8 POWER P.C.B.
8 9 10 11 12 13 9 DIGITAL1 (3) P.C.B.
10 AMPPOWER (1) P.C.B.
11 DIGITAL1 (1) P.C.B.
12 DIGITAL2 P.C.B.
13 DAC P.C.B.
14 AMP (2) P.C.B.
15 AMPPOWER (5) P.C.B.
16 AMP (5) P.C.B.
17 POWER TRANSFORMER
18 VIDEO (3) P.C.B.
19 AMP (4) P.C.B.
20 AMPPOWER (4) P.C.B.
21 AMP (1) P.C.B.
22 OPERATION (1) P.C.B.
23 OPERATION (3) P.C.B.
24 DIGITAL1 (2) P.C.B.
25 OPERATION (2) P.C.B.
21 20 19 18 17 16 15 14 26 OPERATION (4) P.C.B.
22 23
Front view
26 25 24
SERVICE PRECAUTIONS /
Safety measures
