 Motorola's Microcomputer Families     I
                         Reliability   I
                       Data Sheets     I
                   Mechanical Data     I
                 Technical Training    I
                  Memory Products      I
Logic and Special Function Products    I
          Development Systems and      II.
               Board-Level Products
                      MOTOROLA
                MICROCOMPUTERS

                                                                     Prepared by
                                                     Technical Information Center



This book is intended to provide the design engineer with the technical data
needed to completely and successfully design a microcomputer based
system. The data sheets for Motorola's microcomputer and peripheral com-
ponents are included.

The information in this book has been carefully checked; no responsibility,
however, is assumed for inaccuracies. Furthermore, this information does
not convey to the purchaser of microelectronic devices any license under
the patent rights of the manufacturer.

Additional information about memory products, technical training, and
system development products is also provided. For further marketing and
applications information, please contact:

                Motorola Inc.
                MOS Integrated Circuits Group
                Microprocessor Division
                Austin, Texas
                (512)928-6800




                                                                      Series C
                                                               Second Printing
