Image preview - the first page of the document
>> Download 8p_tm documenatation <<
Text preview - extract from the document
OKIPAGE8p
LED Page Printer
Troubleshooting Manual
with Component Parts List
(ODA/OEL/INT)
All specifications are subject to change without notice.
CONTENTS
1. OUTLINE..................................................................................................... 1
2. TOOLS ........................................................................................................ 1
3. CIRCUIT DESCRIPTION ............................................................................ 2
3.1 Outline ..................................................................................................................... 2
3.2 CPU and Memory .................................................................................................... 4
3.3 Reset Control ........................................................................................................... 6
3.4 EEPROM Control ..................................................................................................... 7
3.5 Centronics Parallel Interface .................................................................................... 8
3.6 Front Operator Panel ............................................................................................... 9
3.7 LED Head Control ................................................................................................. 10
3.8 Motor and clutch control ........................................................................................ 12
3.9 Fuser Temperature Control .................................................................................... 14
3.10 Sensor Control ....................................................................................................... 17
3.11 Cover Open ........................................................................................................... 18
3.12 Power Supply Part ................................................................................................. 19
4. TROUBLESHOOTING .............................................................................. 21
4.1 Troubleshooting Table ............................................................................................ 21
4.2 Troubleshooting Flowchart ..................................................................................... 23
5. CIRCUIT DIAGRAM .................................................................................. 27
6. COMPONENT PARTS LIST
1. OUTLINE
This manual has been written to provide guidance for troubleshooting of the OKIPAGE8p Printer
(primarily for its printed circuit boards), on an assumption that the reader is knowledgeable of the
printer. Read the maintenance manual for this printer if necessary.
Note:
1. High voltage power supply board and power supply unit containing a high voltage power
supply is dangerous. From the viewpoint of the safety standards, the local repairing of a
defective board is not allowed. Thus, the objects to be locally repaired as a result of
troubleshooting are switches.
2. TOOLS
For troubleshooting the printer, the tools listed below may be needed in addition to general
maintenance tools.
Tool Remarks
Oscilloscope Frequency response 100 MHz or higher
Soldering iron A slender tip type, 15-20 watts
-1-
3. CIRCUIT DESCRIPTION
3.1 Outline
The circuit of OKIPAGE8p consists of a main control board, a main high voltage power supply
board, a sub-high voltage power supply board and a power supply unit. The block diagram is
shown in Fig. 3-1. The main control board controls the reception and transmission of data with
a host I/f and processes command analysis, bit image development, raster buffer read. It also
controls the engine and high voltage outputs.
(1) Reception control
The main control board has one parallel I/F port which is compliant to the IEEE 1284
specification.
The parallel I/F port can specify the following item when set by the control panel:
I-PRIME: Enabled/ Disabled
(2) Command analysis processing
The OKIPAGE8p printers support PCL5e (Hewlett Packard LJ6P compatible).
An edit task fetches data from the receive buffer, analizes commands, and reconstructs the
data in such a way that print data are aligned from up to down and from right to left; then it
writes the resultant data into a page buffer with such control data as print position coordinate,
font type, etc. added.
(3) Font Processing
When one page editing is finished, a developing task makes an engine start and fetches data
from the page buffer synchronizing with a printing operation; then it developes the fetched
data to a bit map as referring to data from a character generator, and writes the resultant data
into the raster buffer (of band buffer structure).
(4) Raster buffer read
As controlling the engine operation, an engine task sends data from the raster buffer to the
LED head.
(5) High voltage control (main, sub)
The high voltage control circuit in the CPU.
The high voltage power supply board generates high voltage outputs, and have sensors, LED for
display.
The power supply unit generates +26VDC output, +5DC output.
-2-
Motor
M
PLUNGER LED HEAD
PJ HEAD1 HEAD2 MOTOR Main PCB NMA- Red
Amber
5V 0V Amber
Motor Driver EEPROM
MTD2005F 1kb
0V
Figure 3-1 OKIPAGE8p Block Diagram
OPTION
DRAM 2MB PCB N4A-
CPU Serial I/F O
DRAM P
(NKK3 or 5) 1M x 16 T
Parallel I DRAM
CENT
-3-
I/F Data Bus O 1M x 16
(x16) N
LS07 Address Bus OSC M-ROM DRAM 4MB
10MHz 4M x 16
Mask ROM 8MB
OSC
7MHz LSI
LC26023A HC244
+26V +5V 0V 0VP
RST
POWER HIVOL HIVOL2
High Voltage Power Unit
High Voltage Power Unit P6L
Power Supply Unit P2H
AC ID Unit
(120V/ 230V)
Heater
(Halogen lamp)
3.2 CPU and Memory
(1) CPU (NKK3 or NKK5)
CPU core RISC CPU (MIPS R3000)
CPU clock 7.067 MHz, Internal CPU CLK 28.268 MHz
Data bus width External 16 bits, Internal 32 bits
(2) Program ROM
ROM capacity 8M-bytes (Mask ROM)
ROM type 64Mbits (4M x 16 bits)
Access time 100 nsec
(3) Resident RAM
RAM capacity 2M bytes (1Mx 16 bits)
RAM type 16M bits (1M x 16 bits)
Access time 60 ns
(4) Option Board
RAM capacity 4M bytes (16M bits D-RAM two pieces)
RAM type 16M bits D-RAM two pieces
Access time 60 n
The block diagram of CPU and memory circuit is shown in Fig. 3-2.
-4-
CPU
D00 to D15
CS0
CS0
Mask ROM
A00 to A25 (4M x 16 bits)
RD
RAS0
RAS1
RAS2
RAS0 DRAM
CAS0 (1M x 16 bits)
CAS1
RD/WR
CAS0, 1 Main
control
board
CAS0, 1 WR RAS1, 2 Option
board
DRAM
RAS1, 2 WR 4M Byte
CAS0,1
Figure 3-2 Block Diagram of CPU & Memory in OKIPAGE8p
-5-
3.3 Reset Control
When power is turned on, RST-N signal is generated by RST.
+5V +5V
RST CPU
1 172
3 RSTN
2
Power ON Power OFF
+5V
CL RST-N
-6-
3.4 EEPROM Control
The BR93LC46A on the main control board is an electrical erasable/programmable ROM of 64-
bit x 16-bit configuration. Data input to and output from the ROM are bidirectionally transferred
in units of 16 bits through I/O port (EEPRMDT-P) in serial transmission synchronized with a clock
signal from the CPU.
IC4
SSTXD-P 3
DI DO
154 4
1 EEPROM
EEPRMCSO-P
CPU CS
150
SK
EEPRMCLK-P 2
151
The EEPROM operates in the following instruction modes.
Instruction Start bit Operation Address Data
code
Read (READ) 1 10 A5 to A0
Write Enabled (WEN) 1 00 11XXXX
Write (WRITE) 1 01 A5 to A0 D15 to D0
Write All Address (WRAL) 1 00 01XXXX D15 to D0
Write Disabled (WDS) 1 00 00XXXX
Erase 1 11 A5 to A0
Chip Erasable (ERAL) 1 00 10XXXX
Write cycle timing (WRITE)
Min. 450 ns
CS STATUS
SK 1 2 4 9 10 25
DI 1 0 1 A5 A4 A1 A0 D15 D14 D1 D0
Max. 500 ns
DO BUSY READY
HIGH-Z
Max. 10 ms
Read cycle timing (READ)
CS
SK 1 2 4 9 10 25 26
DI 1 1 0 A5 A4 A1 A0
DO 0 D15 D14 D1 D0 D15 D14
HIGH-Z
-7-
3.5 Centronics Parallel Interface
The CPU sets a BUSY-P signal to ON at the same time when it reads the parallel data (PDATA1-
P to PDATA 8-P) from the parallel port at the fall of PSTB-N signal. Furthermore, it makes the store
processing of received data into a receive buffer terminate within a certain fixed time and outputs
an ACK-N signal, setting the BUSY-P signal to OFF.
CENT
87, 88, 91 to 96
DATA8-P
PDATA1-P to PDATA8-P to
DATA1-P
97 2 to 9
PSTB-N
STB-N
Q4 1
85 PBUSY-P
BUSY-P
11
86 PACK-N
ACK-N
10
CPU 83 PRE-P
PE-P
12
81 PSEL-P
SEL-P
13
79 PERROR-P
FAULT-N
32
80 PINIT-N
IPRIME-N
31
82 PSELIN-N
SELIN-N
36
84 PALITOFD-N
AUTOFEED-N
14
+5V or High Level +5V
18
PARALLEL DATA
(DATA BITs 1 to 8)
