Image preview - the first page of the document
Acer LCD Monitor AL1917 LE1918 Schematics


>> Download Acer LCD Monitor AL1917 LE1918 Schematics documenatation <<

Text preview - extract from the document
  Acer                                                Service Manual

                  Chapter 4- Disassembly & Assembly
1. Exploded Diagram




                                    9
  Acer                                                                             Service Manual
                                 Attachment 1- Bill of Material
PCBA P+I
ITEM PART NUMBER DESCRIPTION                                Q'TY    LOCATION
  1 412140002380R IC LTV817M-PR VDE       (LITE-ON)           1     IC801
                   P=10mm ROHS
 1.1 412140001390R IC EL817M-B ROHS     (EVERLIGHT           1
  2 410500072270R XSTR AOP605 N&P-CH PDIP-8(AOS              2      U501,U502
  3 412000225280R IC TDA7496L AMPLIFIER(ST)ROHS              1      U701
                   W/DC VOLUME CONTROL/POWERDIP
 3.1 412000225020R IC TDA7496LK DIP-20(UTC)ROHS              1
  4 411050005020R DIO BRDG BL4-06-BF52-LF                    1      D801
                   600V/4A FRONTIER ROHS
  5 418105058960R CAP CD SL 5pF 3KV D,ST, ROHS               4      C524,C525,C526,C527
                   CC45SL3FD050DYPN(TDK)
  6 420431014082R CAP SEK 100uF/450V M,105     CF            1      C805
                      18x40(2.5),ROHS
 7    420421020102R   CAP EC 1000uF/10V M,105   N-F          1      C812
                      10x16(L-ESR) ROHS
 8    420426810210R   CAP SD 680uF/25V M 105    F            2      C808,C826
                      10x20 ROHS
 9    416202223610R   CAP MEY 2200pF 250V M Y2 Y5V           2      C801,C806
                      P=7.5mm ROHS
 10   416202224610R   CAP MEY 2200pF 400V M Y,F10mm          1      C820
 13   416204724610R   CAP MEY 4700pF 400V M Y,F10mm          1      C824
 14   416194743011R   CAP MEX 0.47uF 275V K X2,F15           1      C804
 15   425000010530R   COIL CHK 5uH 7.8X10 CHK-053 0          2      L802,L803
                      181085R0L-LFR ROHS
 16   426000050070R   CHOKE L-FILTER 12mH LIN-007            1      L801
                      ET-20
 17   426000090510R   XFMR 750u@1K,+-8%,3m,113m,SPW-         1      T801
                      051,DIP-11,NC-H0494-1 ROHS
 18   426000090490R   XFMR SW 93uH EEL19 DIP SPW-049         2      T501,T502
 19   432009400701R   NTC 5 4A 10 P=5mm, F ROHS              1      RT801
 20   430613420290R   FUSE SLOW 2,250,Axial Lead,3.6         1      F801
                      x10mm ROHS
 21   440149000110R   SKT AC 10A/250V U/C/V,                 1      P801
                      TU-301-SP-SRB-AD7
21.1 440149000120R    SKT AC 10A/250V U/C/V,                 1
                      CDJ-3D-B-6.0B
 22   430300600070R   HRN ASS'Y 6P 100mm UL1007#24           1      CN801
 23   430637020020R   WFR. 2P P=3.5mm 90
