Exploded Diagram
THE SYSTEM
88 Chapter 6
LOGIC UPPER ASSY
Aspire 1400 Series
Chapter 6 89
LCD 14.1"
Model Name
Aspire 1400 Series
90 Chapter 6
LCD 15"
Aspire 1400 Series
Chapter 6 91
DVD ASSY
02
Aspire 1400 Series
NOTE: The exploded diagrams for CD-ROM, CD-RW, DVD-ROM and DVD-RW module are the same.
Therefor, we put only DVD ASSY exploded diagram as your referance. Please also refer to the FRU list
below for more information on different models and part numbers. This diagram only explains the
relevent location for each part. The part on the exploded diagrams may be different from its actual
looks.
92 Chapter 6
FDD ASSY
02
HDD (W/O HDD) ASSY
02
Chapter 6 93
Picture No. Partname And Description Part Number
CPU/Processor
CPU Willamette 1.7Ghz/400FSB, 256OD 478pin 01.WILAM.1GV
D-0
Memory
256M SDRAM Mitsubishi MH32S64AVS-6TA-PE 72.03264.AON
256M SDRAM Infineon HYS64V32220GDL-75- 72.64322.CON
C2
256MB SDRAM APACER 71.84470.111
LCD
LCD 14.1" ASSY LCD MODULE 14.1" XGA AU 6M.A02V5.019
and LCD 15"
ASSY LCD MODULE 14.1" XGA SAMSUNG 6M.A02V5.020
ASSY LCD MODULE 15.0" XGA AU 6M.A02V5.021
ASSY LCD MODULE 15.0" XGA HANNSTAR 6M.A02V5.022
ASSY LCD MODULE 15.0" SXGA+ CPT 6M.A02V5.023
ASSY LCD MODULE 15.0" SXGA HANNSTAR 6M.A02V5.024
ASSY LCD MODULE 15.0" SXGA HITACHI 6M.A02V5.025
ASSY LCD MODULE 15.0" UXGA IBM 6M.A02V5.026
001-LCD LCD 14.1" TFT XGA UB141X03 (AU) LK.A0205.001
14.1" and
LCD 15"
LCD 14.1" TFT XGA LTN141XF-L05 LK.A0206.001
(SAMSUNG)
LCD 15.0" TFT XG (AU)AB150XN01 LK.A0205.002
LCD 15.0" TFT XGA HSD150PX11- LK.A0207.001
B(HANNSTAR)
014-LCD LCD INVERTER 19.A02V5.001
14.1" and
LCD 15"
009-LCD LCD BRACKET L 14" 33.A02V5.007
14.1" and
LCD 15
LCD BRACKET L 15" XGA 33.A02V5.009
LCD BRACKET L15" SXGA+/UXGA 33.A02V5.011
LCD BRACKET L15" SXGA+ HITACHI 33.A02V5.013
Note: The image is for L and R LCD brackets.
010-LCD LCD BRACKET R 14" 33.A02V5.008
14.1" and
LCD 15"
LCD BRACKET R 15" XGA 33.A02V5.010
LCD BRACKET R15" SXGA+/UXGA 33.A02V5.012
LCD BRACKET R15" SXGA+ HITACHI 33.A02V5.014
Note: The image is for L and R LCD bracket.
94 Chapter 6
Picture No. Partname And Description Part Number
004-LCD LCD PANEL WITH LOGO 60.A02V5.003
14.1" and
LCD 15"
005-LCD LCD BEZEL WITH PRINTING-14.1" 60.A02V5.004
14.1" and
LCD BEZEL WITH PRINTING-15.0" 60.A02V5.005
LCD 15"
006-LCD COAXIAL CABLE 14.1" AU 50.A02V5.007
14.1" and COAXIAL CABLE 14.1" SAMSUNG 50.A02V5.008
LCD 15"
COAXIAL CABLE 15" XGA AU 50.A02V5.010
COAXIAL CABLE 15"XGA HANNSTAR 50.A02V5.011
COAXIAL CABLE 15" SXGA+ CPT 50.A02V5.012
COAXIAL CABLE 15" SXGA+ HANNSTAR 50.A02V5.013
COAXIAL CABLE 15" SXGA+ HITACHI 50.A02V5.014
COAXIAL CABLE 15" UXGA IBM 50.A02V5.015
NS LCD HINGE ASSEMBLY (L&R) 6K.A02V5.001
PCMCIA Slot/PC Card slot
NS PCMCIA SLOT 21.A02V5.001
FDD/Floppy Disk Drive
FDD ASSY FDD MODULE, MITSUMI 6M.A02V5.011
FDD MODULE, PANASONIC 6M.A02V5.012
FDD 1.44MB SLIM MITSUMI/D353G-2938 HKF.0226.002
001-FDD FDD DRIVE PANASONIC HKF.0226.001
ASSY
Chapter 6 95
Picture No. Partname And Description Part Number
002-FDD FDD DOOR MITSUMI 42.A02V5.018
ASSY
FDD DOOR PANASONIC 42.A02V5.019
HDD/ Hard Disk Drive
NS HDD 2.5 20G IBM CASCADE KH.25202.001
IC25N020ATCS04-0 07N8325 FW:A71A
Optical Drive
DVD ASSY DVD-ROM MODULE 8X TOSHIBA 6M.A02V5.005
DVD-ROM MODULE 8X MKE 6M.A02V5.006
DVD-ROM MODULE 8X QSI 6M.A02V5.007
DVD-RW COMBO MODULE TOSHIBA 6M.A02V5.008
DVD-RW COMBO MODULE TEAC 6M.A02V5.010
001-DVD DVD-ROM 8X TOSHIBA SD-C2502 KV.00801.001
ASSY (w/o
DVD-ROM 8X MKE SR-8176 KV.00802.001
optical lock
on the DVD-ROM 8X QSI SDR-081 KV.00803.001
exploded DVD+RW COMBO 8X TOSHIBA/SDR21202 HKV.0210.001
diagram
DVD+RW COMBO 8X TEAC/DW-28E-085 KO.00802.001
Cables
016-Logic FFC-LED 20 PIN (CABLE-FFC TOUCHPAD TO 50.A02V5.001
Upper LED BOARD)
015-Logic FFC-TOUCHPAD (TOUCHPAD BOARD TO 50.A02V5.002
Upper TOUCHPAD)
017-Logic FFC-LED 22 PIN (M/B TO TOUCHPAD BOARD) 50.A02V5.003
Upper
96 Chapter 6
Picture No. Partname And Description Part Number
005-Logic FPC-FDD LF-1252(M/B TO TOUCHPAD 50.A02V5.004
Upper BOARD)
004-FDD FDD FPC MITSUMI 50.A02V5.005
ASSY
FDD FPC PANASONIC 50.A02V5.006
NS POWER CORD CONTINENTAL 27.A02V5.001
POWER CORD DANISH 27.A02V5.002
POWER CORD ITALIAN 27.A02V5.003
POWER CORD PRC 27.A02V5.004
POWER CORD SWISS 27.A02V5.005
POWER CORD UK 27.A02V5.006
POWER CORD US 27.A02V5.007
003-HDD HDD CONNECTOR 22.A02V5.002
(W/O HDD)
ASSY
Boards
POWER BOARD 55.A02V5.002
252-Logic LED BOARD 55.A02V5.003
Upper
253-Logic TOUCHPAD BOARD 56.A02V5.001
Upper
Chapter 6 97
Picture No. Partname And Description Part Number
NS MODEM CARD 54.A02V5.001
NS WIRELESS LAN CARD 54.A02V5.002
Adapter
NS AS1400 90W DELTA ADAPTER(3-PIN) AP.0201.001
ADAPTER-API AP.0201.002
Battery
NS BATTERY LI-ION 12 CELL-SONY BT.A0201.002
BATTERY LI-ION 12 CELL-PANASONIC BT.A0201.001
Keyboard
NS AS1400 KEYBOARD CHICONY Arabic KB.A0203.010
AS1400 KEYBOARD CHICONY Belgium KB.A0203.012
AS1400 KEYBOARD CHICONY Traditional KB.A0203.005
Chiese
AS1400 KEYBOARD CHICONY Czech KB.A0203.014
AS1400 KEYBOARD CHICONY Danish KB.A0203.017
AS1400 KEYBOARD CHICONY French KB.A0203.006
AS1400 KEYBOARD CHICONY German KB.A0203.003
AS1400 KEYBOARD CHICONY Hungaian KB.A0203.015
AS1400 KEYBOARD CHICONY Italian KB.A0203.004
AS1400 KEYBOARD CHICONY Norway KB.A0203.016
AS1400 KEYBOARD CHICONY Portuguese KB.A0203.009
AS1400 KEYBOARD CHICONY Spanish KB.A0203.008
AS1400 KEYBOARD CHICONY Sweden KB.A0203.013
AS1400 KEYBOARD CHICONY Swiss/G KB.A0203.007
98 Chapter 6
Picture No. Partname And Description Part Number
AS1400 KEYBOARD CHICONY Thai KB.A0203.011
AS1400 KEYBOARD CHICONY Turkish KB.A0203.018
AS1400 KEYBOARD CHICONY UK KB.A0203.002
AS1400 KEYBOARD CHICONY US KB.A0203.001
Case/Cover/Bracket Assembly
NS MIDDLE COVER 42.A02V5.001
309-The DIMM COVER 42.A02V5.002
System
NS HEATSINK COVER 42.A02V5.003
301-The LOWER CASE W/O SPEAKER-INCLUDING 60.A02V5.001
System BATTER LATCH, NOB, SPRING
003-Logic UPPER CASE 60.A02V5.002
Upper
001-Logic EMI SHIELDING 31.A02V5.001
Upper
314-The OPTICAL BRACKET 33.A02V5.001
System
Chapter 6 99
Picture No. Partname And Description Part Number
008-Logic TOUCHPAD BRACKET 33.A02V5.002
Upper
311-The HEATSINK BRACKET 33.A02V5.003
System
002-Logic LED BRACKET 33.A02V5.004
Upper
310-The D-SUB BRACKET 33.A02V5.005
System
312-The CPU SUPPORT BRACKET 33.A02V5.006
System
006-Logic HINGE SADDLE-R 34.A02V5.001
Upper Note: The image includes right and left hinge
saddles.
007-Logic HINGE SADDLE-L 34.A02V5.002
Upper Note: The image includes right and left hinge
saddles.
NS BATTERY LATCH 42.A02V5.004
NS BATTERY LATCH KNOB V42.A02V5.005
100 Chapter 6
Picture No. Partname And Description Part Number
NS BATTERY LATCH SPRING 34.A02V5.003
NS ANTENNA COVER-R 42.A02V5.006
Note: The image includes the right and left
antenna covers.
NS ANTENNA COVER-L 42.A02V5.007
Note: The image includes the right and left
antenna covers.
001-HDD HDD CARRIER 42.A02V5.020
(W/O HDD)
ASSY
005-HDD HDD EMI PLATE 34.A02V5.004
(W/O HDD)
ASSY
003-DVD OPTICAL LOCK 22.A02V5.001
ASSY
Others
001-The SPEAKER ASSY(R&L) 6K.A02V5.002
System
018-Logic TOUCHPAD (BACK SIDE) 31.A02V5.002
Upper
Chapter 6 101
Picture No. Partname And Description Part Number
313-The FAN 31.A02V5.003
System
NS HEATSINK 23.A02V5.001
NS ANTENNA LINE-L 50.A02V5.016
ANTENNA LINE-R 50.A02V5.017
Screws
315-Logic SCREWLOCK, 6NUT 86.A02V5.001
Upper
SCREW, M1.7X2.5L 86.A02V5.002
SCREW, TPB 2.0X4 86.A02V5.003
SCREW, M2.5X3 86.A02V5.004
307-The SCREW, M2.5X4 86.A02V5.005
System
SCREW, M2.5X8 86.A02V5.006
SCREW, M2X3 86.A02V5.007
308-The SCREW,M2X4 86.A02V5.008
System
SCREW, M2X6 86.A02V5.009
002-HDD SCREW, M3X3 86.A02V5.010
ASSY
SCREW, TPB 1.7X3.5 86.A02V5.011
102 Chapter 6
