Image preview - the first page of the document
>> Download datasheet documenatation <<Text preview - extract from the document AOZ1210
EZBuckTM 2A Simple Buck Regulator
General Description Features
The AOZ1210 is a high efficiency, simple to use, 2A buck 4.5V to 27V operating input voltage range
regulator flexible enough to be optimized for a variety of 70m internal NFET, efficiency: up to 95%
applications. The AOZ1210 works from a 4.5V to 27V
Internal soft start
input voltage range, and provides up to 2A of continuous
output current on each buck regulator output. The output Output voltage adjustable down to 0.8V
voltage is adjustable down to 0.8V. 2A continuous output current
Fixed 370kHz PWM operation
Cycle-by-cycle current limit
Short-circuit protection
Thermal shutdown
Small size SO-8 packages
Applications
Point of load DC/DC conversion
Set top boxes
DVD drives and HDD
LCD Monitors & TVs
Cable modems
Telecom/Networking/Datacom equipment
Typical Application
C7
VIN
C1
22
