Macintosh IIsi Teardown




                          Macintosh IIsi Teardown

                                  Step 1 -
                                     Yes, it only has a floppy drive. Its also 20 years old!
                                     Lets begin the repair guide!




                                  Step 2
                                     Pull on the 2 tabs and rotate the top cover towards the
                                     front. Remember to remove the one screw.
                                     Ports from left to right: Audio in and out, Serial Ports,
                                     SCSI, Video, External Floppy, and ADB.
                                     I have a nubus Ethernet card installed. Some may have
                                     had an expansion card added.
