Image preview - the first page of the document
>> Download Installing-Hard-Drive-1062 documenatation <<
Text preview - extract from the document
Installing Mac mini Model A1283 Hard Drive
Installing Mac mini Model A1283 Hard Drive
Step 1 - Hard Drive
In this step, make sure to only disconnect
the connector from its socket, and not the
entire socket from the interconnect board.
Use the tip of a spudger to gently pry the hard drive
thermal sensor connector away from its socket on the
interconnect board. Make sure to only detach the
connector and not the socket that is soldered to the
interconnect board.
