Image preview - the first page of the document



>> Download Installing-Logic-Board-1070 documenatation <<

Text preview - extract from the document

Installing Mac mini Model A1283 Logic Board




        Installing Mac mini Model A1283 Logic Board

                                              Step 1 - Logic Board
                                               Use the flat end of a spudger to pry the power button
                                               cable connector up off the logic board.




                                              Step 2
                                               Use the flat end of a spudger to pry the sleep light
                                               cable connector up off the logic board.
                                               During reassembly, make sure the cable
                                               does not come near the lug on the bottom
                                               case (shown in green) to avoid damaging
                                               the cable.
