Image preview - the first page of the document



>> Download Installing-Antenna-Plate-3111 documenatation <<

Text preview - extract from the document

Installing Mac mini Model A1347 Antenna Plate




      Installing Mac mini Model A1347 Antenna Plate
         Tools used in this guide
              2mm Hex Screwdriver
              Spudger
              T6 Torx Screwdriver
              T8 Torx Screwdriver



                                            Step 1 - Bottom Cover
                                                Place your thumbs in the depressions cut into the
                                                bottom cover.
                                                Rotate the bottom cover counter-clockwise until the
                                                white dot painted on the bottom cover is aligned with
                                                the ring inscribed on the outer case.
