Image preview - the first page of the document



>> Download Installing-Fan-3108 documenatation <<

Text preview - extract from the document

Installing Mac mini Model A1347 Fan




               Installing Mac mini Model A1347 Fan
         Tools used in this guide
              T6 Torx Screwdriver



                                       Step 1 - Bottom Cover
                                          Place your thumbs in the depressions cut into the
                                          bottom cover.
                                          Rotate the bottom cover counter-clockwise until the
                                          white dot painted on the bottom cover is aligned with
                                          the ring inscribed on the outer case.
