Image preview - the first page of the document



>> Download Installing-Hard-Drive-3112 documenatation <<

Text preview - extract from the document

Installing Mac mini Model A1347 Hard Drive




         Installing Mac mini Model A1347 Hard Drive

                                               Step 1 - Hard Drive
                                                 Remove the following three screws:
                                                       One 5.0 mm T8 Torx or 2.0 mm Hex screw (either
                                                       will work)
                                                       One 16.2 mm T6 Torx screw
                                                       One 26 mm T6 Torx standoff




                                              Step 2
                                                 Carefully pull the wires for both hard drive thermal
                                                 sensors upward to lift their connectors up and out of
                                                 their respective sockets on the logic board.
