Image preview - the first page of the document
>> Download Installing-Graphics-Card-1620 documenatation <<
Text preview - extract from the document
Installing Power Mac G4 MDD Graphics Card
Installing Power Mac G4 MDD Graphics Card
Tools used in this guide
Phillips #0 Screwdriver
Step 1 - Case
The Power Mac G4 MDD: the last, and the fastest G4-
based Mac. This computer boasted up to a Dual
1.42GHz PowerPC G4 CPU (though I have a single
1.25GHz).
Six USB ports.
Four FireWire ports.
Assorted SCSI (SCSI50/SCSI68)
Assorted Audio
Video (ADC & DVI)
Networking (RJ-45 Ethernet/56k Modem)
Some later model MDD's (such as the dual 1.42GHz)
Have a FireWire 800 Port Here:
