Image preview - the first page of the document



>> Download Repairing-MagSafe-End-3090 documenatation <<

Text preview - extract from the document

Repairing MagSafe Magnetic End




                  Repairing MagSafe Magnetic End

                                  Step 1 - MagSafe End
                                     This is the hyper extended end of a magsafe. It is no
                                     longer working due to the frayed wire having pulled
                                     apart.




                                  Step 2
                                    Cut the wire of the magsafe some distance back from
                                    the manetic end. I used about 4 inches but in reality
                                    you can get much closer like maybe an inch, as you will
                                    see in the next step.
