Apple A4 Teardown




                               Apple A4 Teardown

                                     Step 1 -
                                       Apple's A4 microprocessor is the brain of the iPad.
                                            The A4 is an ARM processor featuring package-
                                            on-package construction to improve the speed
                                            and efficiency of internal processes.
                                       The silkscreen on the A4 reads N26CGM0T APL0398
                                       339S0084 YNL215X0. But that's not very
                                       interesting--those numbers don't mean much to us,
                                       either. Let's see what we can find inside.
