Image preview - the first page of the document

>> Download PAPAMY1502046CE documenatation <<

Text preview - extract from the document
                                                                                                                          Order No: PAPAMY1502046CE

                                                                                                            Indoor Unit      Outdoor Unit
                                                                                                          CS-RE9RKEW          CU-RE9RKE
                                                                                                         CS-RE12RKEW         CU-RE12RKE
                                                                                                         CS-RE15RKEW         CU-RE15RKE

                                                       HE AT
                                                                                               SPE E D
                                                        DRY                                    SWING



                                                                            TEMP      AIR SWING

                                                       POWE RFUL/
                                                         QUIE T         FAN SPEE D

                                                           ON                              SET

                                                               1              2            3

                                                           OFF                            CANCEL
                                                                                     AC        RC

                                                          SE T     CHE CK   CLO CK    RESE T

   This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
    Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
      service or repair the products dealt with in this service information by anyone else could result in serious injury or death.

                                              PRECAUTION OF LOW TEMPERATURE
      In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
