Text preview - extract from the document
Disassembly and Reassembly


* Reinstall in reverse order.          Gear-Cam


                                                     * Align the Gear-Cam with the Gear-Tray as
                                                       shown ing Figure 3-6, then mount the Tray-Disc.
                                          Gear-Cam




  Gear-Cam


Gear-Cam
Timming Point




                  Gear-Cam


                          Figure 3-6




                                                     * When assembling the Tray-Disc,take extreme
                                                       care not to engage with Gear-Synchro.




                                                              Gear-Synchro




                                                     Insert


                                                          Gear-Disc




                          Figure 3-7
