Image preview - the first page of the document



>> Download scc_p documenatation <<

Text preview - extract from the document

                                                    Scart P.C.B.(Component Side)
                                               Diode               Capacitor
                                               D3901     C-7       C3916     A-8
                                               Connector           C3917     A-8
                                               JK3901    B-1       C3918     A-7
                                               JK3904    B-5       C3919     B-7
                                               JK3905    C-5       C3921     A-7
                                               PS3901 A-2          C3924     B-7
                                               PS3902 A-4          C3928     C-9
                                               PS3903 A-8          C3929     C-9
                                               Capacitor           C3931     C-9
                                               C3909     B-3       C3932     D-9
                                               C3910     B-9       C3933     D-8
                                               C3911     B-9       C3935     C-8
                                               C3914     C-7       Resisitor
                                               C3915     B-7       R3924     C-7



    Scart P.C.B.
D




C




B




A


                                                              DMR-E95HEB/EG
    (COMPONENT SIDE)                                          Scart P.C.B. (Component Side)
                                                              (REP3682A)
       1               2   3   4   5   6   7              8                        9
