PCZ1004037CE


>> Download PCZ1004037CE documenatation <<

Text preview - extract from the document
                                                                                                      ORDER No. PCZ1004037CE
                                                                                                                  REVISION 3




Service Manual
                                                                     Colour LCD Television

                                                                                                         TX-L32S20E
                                                                                                         TX-L32S20L
                                                                                                         TX-LF32S20
                                                                                                        TX-L32S20ES
                                                                                                         TX-L37S20E
                                                                                                         TX-L37S20L
                                                                                                         TX-LF37S20
                                                                                                        TX-L37S20ES



                                                                                        GLP25 Chassis
Specifications
 (Information in brackets [ ] refers to model 32")

     Power Source:               220-240V AC, 50Hz
     Rated Power Consumption:    145W [103W]
     Stand-by Power Consumption: 0.25W (Without monitor out recording)
                                 13W (With monitor out recording)
      Aerial Impedance:                   75 unbalanced, Coaxial Type
      Receiving System:
                                          PAL-I/H, B/G, D/K
                                          SECAM B/G, D/K, L/L'
                                          PAL-525/60 (AV only)
                                          DVB-T (Digital Terrestrial Services (MPEG2 and MPEG4-AVC(H.264))
                                          DVB-C (Digital cable services (MPEG2 and MPEG4-AVC(H.264))
                                          M.NTSC (AV only)
                                          NTSC (AV only)

      Receiving Channels:
                                          VHF E2-E12                    VHF H1-H2 (ITALY)
                                          VHF A-H (ITALY)               VHF R1-R2
                                          VHF R3-R5                     VHF R6-R12
                                          UHF E21-E69                   CATV (S01-S05)
                                          CATV S1-S10 (M1-M10)          CATV S11-S20 (U1-U10)
                                          CATV S21-S41 (Hyperband)      VHF A-J (IRELAND)

      Operating Conditions:               Temperature: 0
