Image preview - the first page of the document
>> Download aa_pa_v documenatation <<
Text preview - extract from the document
REF NO. IC6901
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
CD PLAY 0 0 0 0 3.0 1.3 1.9 4.2 2.6 1.3 1.3 0 5.0 -24.6 -24.6 -22.2 -22.2 -19.0 -19.8 -17.3
STANDBY 0 0 0 0 2.9 1.1 2.0 4.1 2.6 1.0 1.0 0 5.0 -24.6 -24.6 -24.6 -22.2 -15.0 -12.6 -15.0
REF NO. IC6901
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY -24.6 -24.6 -24.6 -19.8 -20.0 -24.6 -24.6 -24.6 -17.3 -25.1 -15.1 -15.1 -22.5 -22.4 -22.4 -22.4 -22.4 -22.4 -22.4 -22.4
STANDBY -24.6 -24.6 -22.2 -15.0 -15.0 -22.2 -24.6 -22.2 -10.2 -25.1 -15.1 -15.1 -22.5 -22.4 -22.4 -22.4 -22.4 -22.4 -22.4 -22.4
REF NO. IC6901
MODE 41 42 43 44
CD PLAY -22.4 -22.4 5.0 0
STANDBY -22.4 -22.4 5.0 0
REF NO. Q6910
MODE E C B
CD PLAY 0 4.2 0
STANDBY 0 4.2 0
SA-PT570EB/EG/EP PANEL P.C.B.
