Image preview - the first page of the document
>> Download aa_po_v documenatation <<
Text preview - extract from the document
Ref No. IC701 IC702 IC703
MODE 1 2 3 4 5 6 7 8 1 2 3 1 2 3
CD PLAY 5.9 0.9 2.4 14.2 159 - 0 0 4.2 2.5 0 4.5 0 3.3
STANDBY 6 1 2.4 14.2 159.3 - 0 0 4.2 2.5 0 4.5 0 3.3
Ref No. Q701
MODE E C B
CD PLAY 0 0.1 0.8
STANDBY 0 0.1 0.8
SA-PTX7EB/EG AC-INLET P.C.B.
Ref No. IC722 IC723 IC725
MODE 1 2 3 4 5 1 2 3 4 5 1 2 3 4 5 6 7
CD PLAY 10.9 10.9 9 - 0 11.6 11.6 9 - 0 18.6 - -11.3 -8.1 -11.3 -11 -11.1
STANDBY 10.9 10.9 9 - 0 11.6 11.6 9 - 0 18.8 - -11.4 -8 -11.3 -11 -11.2
Ref No. IC726 IC727
MODE 1 2 3 4 5 1 2 3
CD PLAY 5.2 5.2 0 - - 25.4 2.5 0
STANDBY 5.2 5.2 0 - - 25.3 2.5 0
Ref No. Q721 Q722 Q723 Q724 Q725
MODE E C B E C B E C B E C B E C B
CD PLAY 6.9 17.2 7.5 -7 -11.6 -7.7 0 -7.7 -0.6 -11.6 -11.3 -11.6 0 3.3 -2
STANDBY 6.9 17.2 7.5 -7 -11.6 -7.7 0 -7.7 -0.6 -11.6 -11.3 -11.5 0 3.3 -2
Ref No. Q727 Q728 Q729
MODE E C B E C B 1 2 3 4 5 6
CD PLAY 0 11.3 0 0 0 0.6 11.6 11.6 2 11.6 11.6 11.6
STANDBY 0 11.3 0 0 0 0.6 11.6 11.6 2 11.6 11.6 11.6
Ref No. QR730 QR732 QR733 QR734 QR735
MODE E C B E C B E C B E C B E C B
CD PLAY 0 3.3 0 0 3.3 0 0 0 3.2 0 3.3 0 0 0 0.1
STANDBY 0 3.3 0 0 3.3 0 0 0 3.2 0 3.3 0 0 0 0.1
SA-PTX7EB/EG POWER P.C.B.
Ref No. IC704 IC705
MODE 1 2 3 4 5 6 7 8 1 2 3 4 5 6 7 8
CD PLAY 1 2.3 1 1 0 6.1 17.3 1.6 1 2.2 1 0.8 0 14.1 17.3 1.6
STANDBY 1 2.3 1 1 0 6.1 17.3 1.6 1 2.2 0.8 0.8 0 14.1 17.3 1.6
Ref No. IC706
MODE 1 2 3 4 5 6 7 8
CD PLAY 1 2.3 1 0.8 0 12.4 17.3 1.6
STANDBY 1 2.3 1 0.8 0 12.4 17.3 1.6
Ref No. Q702 Q703 Q704
MODE 1 2 3 4 5 6 1 2 3 4 5 6 1 2 3 4 5 6
CD PLAY 11.7 11.7 6 17.2 11.7 11.7 3.8 3.8 13.6 17.2 3.9 3.8 5.1 5.1 12.3 17.2 5.1 5.1
STANDBY 11.7 11.7 6 17.3 11.7 11.7 3.9 3.9 13.6 17.3 3.9 3.9 5.1 5.1 12.4 17.3 5.1 5.1
Ref No. QR721 QR722 QR725 QR726 QR727
MODE E C B E C B E C B E C B E C B
CD PLAY 0 0 3 0 2.6 0 0 2.5 0 0 0 3 0 2.5 0
STANDBY 0 0 3 0 2.6 0 0 2.5 0 0 0 3 0 2.5 0
SA-PTX7EB/EG REGULATOR P.C.B.
