Image preview - the first page of the document
>> Download aa_tr_v documenatation <<
Text preview - extract from the document
Ref No. IC904
MODE 1 2 3 4 5 6 7 8 9
CD PLAY 5.1 7.5 0.6 7.5 0 7.5 0.6 2.8 5.1
STANDBY 5.1 7.6 0.6 7.6 0 7.6 0.6 2.8 5.1
SA-PTX7EB/EG TRAY LOADING P.C.B.
Ref No. IC800
MODE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
CD PLAY 0 0 0 0 1.9 1.1 0.1 0.1 3.3 1.1 1.1 0 3.3 -24.8 -24.8 -22.6 -22.6 -15.8 -22.6 -18
STANDBY 0 0 0 0 1.9 1.1 0.1 0.1 3.3 1.2 1.1 0 3.3 -24.6 -24.6 -24.6 -24.6 -15.7 -13.4 -17.9
Ref No. IC800
MODE 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40
CD PLAY -24.8 -24.8 -24.8 -18 -18 -24.8 -24.8 -22.6 -24.8 -25.5 -15.9 -16 -23.2 -23 -23 -23 -23 -23 -23.1 -23.1
STANDBY -24.6 -24.6 -22.3 -15.6 -15.6 -22.3 -24.6 -20.1 -11.2 -25 -18 -15.8 -23 -22.9 -22.9 -22.9 -22.9 -22.9 -22.9 -22.9
Ref No. IC800
MODE 41 42 43 44
CD PLAY -23 -23 3.3 0
STANDBY -22.9 -22.8 3.3 0
Ref No. Q800
MODE E C B
CD PLAY 0 0.1 2.8
STANDBY 0 0.1 2.8
SA-PTX7EB/EG PANEL P.C.B.
Ref No. Q841
MODE E C B
CD PLAY 0 4.5 0
STANDBY 0 4.7 0
SA-PTX7EB/EG TACT-2 P.C.B.
