Image preview - the first page of the document
>> Download a_pcb_f documenatation <<
Text preview - extract from the document
A-P.C.Board TXANP01VJJ3
(Foil Side)
A-P.C.Board (Foil Side)
IC TRANSISTOR TP
IC1001 B-3 IC1052 C-2 Q1001 A-2 Q1043 C-1 TPA3 A-5 TPA26 A-2
IC1003 A-3 IC1053 C-1 Q1006 A-3 Q1044 C-1 TPA4 B-5 TPA27 A-2
IC1005 B-2 IC1057 C-3 Q1008 C-4 Q1045 C-1 TPA7 A-2 TPA28 A-2
IC1007 B-1 IC1058 C-1 Q1009 B-4 Q1046 C-1 TPA8 A-5 TPA29 B-1
IC1010 B-4 IC1059 D-1 Q1011 A-5 Q1049 C-1 TPA9 B-5 TPA35 B-2
IC1011 C-4 IC1061 C-4 Q1012 A-5 Q1050 C-1 TPA10 B-4 TPA36 C-1 S-P.C.Board TNPA2343
IC1013 D-5 IC1062 C-4 Q1016 D-3 Q1055 C-3 TPA11 A-3 TPA37 B-1
IC1021 A-4 Q1018 A-4 Q1056 C-3 TPA15 A-2 TPA39 D-4 (Foil Side)
IC1026 D-4 Q1019 B-4 Q1075 A-2 TPA16 B-3 TPA40 C-5
IC1029 D-2 Q1020 D-3 TPA17 B-3 TPA41 C-5
IC1030 D-3 Q1023 B-4 TPA18 B-2 TPA42 B-2 S-P.C.Board
IC1041 B-5 Q1024 B-4 TPA19 A-2 TPA43 C-1 (Foil Side)
IC1042 B-3 Q1025 B-4 TPA20 A-2 TPA44 C-3 TRANSISTOR
IC1043 B-3 Q1026 B-4 TPA21 A-2 TPA45 C-2
Q2001 D-8
IC1044 A-1 Q1028 A-4 TPA22 A-2 TPA46 C-3
Q2002 D-8
IC1046 B-5 Q1037 D-4 TPA23 B-4 TPA48 B-1
Q2003 D-8
IC1051 C-3 Q1040 C-2 TPA24 D-2
Q2004 D-8
ADDRESS INFORMATION ADDRESS INFORMATION
S-P.C.Board TNPA2343
(Component Side)
