A-P.C.Board TXN/A2VKA3
(Component side)
A-P.C.Board (Component Side)
IC
IC2001 E-6 IC3012 B-6
IC2004 D-4 IC3014 C-6
IC2007 D-5 IC3015 C-6
IC2008 E-4 IC3017 C-6
IC2011 E-5 IC3018 C-5
IC2501 D-3 IC3026 D-6
IC2506 D-2 IC3036 D-3
IC2511 E-2 IC3040 C-2
IC2515 E-2 IC3043 C-3
IC2516 E-2 IC3045 E-3
IC2517 E-2 IC3046 E-3
IC2523 C-1 IC3608 D-1
IC2524 E-3 IC3612 C-1
IC3001 B-5 IC3613 E-3
IC3003 D-6 IC3618 E-1
IC3005 C-6 IC3625 E-3
IC3006 E-6 IC3627 E-2
IC3007 D-7 IC3633 C-4
IC3010 B-5 IC3634 C-4
TRANSISTOR
Q2001 E-4 Q3605 C-2
Q2510 D-4 Q3606 D-2
Q2511 D-4 Q3607 E-1
Q3007 A-6 Q3608 E-1
Q3011 C-6 Q3609 E-1
Q3013 C-6 Q3611 D-1
Q3016 D-6 Q3614 D-1
Q3019 E-6 Q3615 E-1
Q3020 E-6 Q3019 E-1
Q3021 D-7 Q3621 A-6
Q3022 D-7 Q3622 E-1
Q3031 C-6 Q3623 E-1
Q3032 B-6 Q3629 A-6
Q3033 B-6
