Image preview - the first page of the document
>> Download j_pcb_fc documenatation <<
Text preview - extract from the document
J-P.C.Board TXN/J1VKA3
(Foil side)
J-P.C.Board TXN/J1VKA3
(Component side)
J-P.C.Board (Component Side)
IC
IC9801 A-2
IC9802 A-1
IC9803 B-1
IC9804 B-5
IC9805 B-2
IC9806 A-3
IC9807 B-4
IC9808 B-4
IC9809 B-4
IC9810 B-2
TRANSISTOR
Q9801 B-4
Q9802 B-4
Q9803 B-4
Q9804 A-4
Q9805 B-5
Q9806 B-5
Q9807 B-3
Q9808 B-3
Q9809 B-3
Q9810 B-3
Q9811 B-3
Q9812 B-3
ADDRESS INFORMATION
