Image preview - the first page of the document
>> Download a_wl_f documenatation <<
Text preview - extract from the document
A-P.C.Board TXANP01PVMZ (LB10NT*) WL-P.C.Board TNPA3143 (LB10NT*)
(Foil Side) TXANP01PVNZ (LB10*) (File Side)
TXANP01PVPZ (LB10V*) WL-P.C.Board(Foil Side)
IC TP
TXANP01P000 (LB10S*) IC1802 D-7 TPA11 E-7
IC1805 E-7 TPA12 D-7
A-P.C.Board(Foil Side)
IC TRANSISTOR TP ADDRESS INFORMATION
IC1003 A-2 IC1023 B-3 Q1006 B-4 Q1022 B-1 TPA11 C-3
IC1004 A-2 IC1024 A-2 Q1008 A-4 Q1034 B-1 TPA12 C-4
IC1005 B-3 IC1027 C-4 Q1011 A-4 Q1040 C-4
IC1006 B-4 IC1029 B-4 Q1012 A-4 Q1041 C-4
IC1009 B-2 IC1032 C-4 Q1014 A-4 Q1043 B-1
IC1010 C-4 IC1040 B-2 Q1015 B-1
IC1012 C-4 IC1051 C-1 Q1016 B-1
IC1013 C-5 IC1052 C-2 Q1017 B-1
IC1016 B-3 IC1053 C-3 Q1018 B-1
IC1018 C-5 IC1068 B-4 Q1019 B-1
IC1021 B-1 IC1083 B-3 Q1021 B-1
ADDRESS INFORMATION
WL-P.C.Board TNPA3143 (LB10NT*)
(Component Side)
WL-P.C.Board(Component Side)
IC
IC1803 B-8 IC1806 A-7
IC1804 B-8
ADDRESS INFORMATION
