Image preview - the first page of the document
DVD-RV32EG-F498


>> Download DVD-RV32EG-F498 documenatation <<

Text preview - extract from the document
                                                                          Ref. No.:   DVD-P-02-002
DVD-Player                Quick Service Manual                            Date: November, 2002
DVD/VCR -
                                        DVD-RV32EG/EE/EB/E Frequence Cases reported ( country )
Combi                       Model:       NV-VD1B/EC/EE/F
                                                                                 Europe


Subject:           Display indicating error code


Symptom:           After the unit is switched on and after
                   message the unit indicates  on the display.



Cause:             No communication between Front Micro Computer and Main Micro Computer.
                   In this case the error code  is generated.

                   possible reason:       - IC 3080 / IC 37001 ( FlashROM ) bad soldering
                                          - IC 3080 / IC 37001 ( FlashROM ) Software hang up
                                          - IC 3001 / IC 37004 ( AV-Decoder ) bad soldering


Remedy:         DVD-RV32                                    NV-VHD1
           1.   IC 3080 resolder                            IC 37001 resolder
           2.   IC 3001 resolder                            IC 37004 resolder
           3.   software update to actual version           software update to actual version
           4.   IC 3080 change                              IC 37001 change
           5.   Decoder-PCB REPD0003A change                AV Decoder-PCB VEP03G15A change



Action on production:

   DVD-RV32:       Decoder PCB REPD0003A-3 with beginning of Index -3
   NV-VHD1 :       AV Decoder PCB VEP03G15A of Index -1
                   Introduction of FR 4 base material for decoder raw PCB.

           Description in Service Manual VRD0206025C2 for NV-VHD1B/EC/EE/F




           F489 is wrong correct F498
