Image preview - the first page of the document
NV-VP30 Timer Rec


>> Download NV-VP30 Timer Rec documenatation <<

Text preview - extract from the document
   PAVCG                                                              Ref. No.:   VCR-C-03-001
                       Quick Service Manual                           Date: July 2003
 VHS-DVD-Combi
                                VCR-DVD Combi       Frequence Cases reported ( country )
                       Model: NV-VP30/25 all models
                                                                       UK


Subject:          No standby after last Timer Recording is finished


Symptom:          When last Timer Recording is finished, the set starts Power On
                  and disc spins up if disc is inside the set.


Cause:            Modification of software implemented side-effect.


Remedy:           Introduction of new software.


                  Change Servo Timer IC IC6001 from C2CBJG000327 (M37761VLRA)

                  to C2CBJG000354 (M37761VLSL)




Improvement on production:

                  Introduce software modification.
                  Start Serial numbers of introduced new software by model :

                  NV-VP30EC-S                     F3ZA06377
                  NV-VP30EB-S                     F3ZA00517
                  NV-VP30EF-S                     F3ZA01514
                  NV-VP25EC-S                     F3ZA01333
