Image preview - the first page of the document



>> Download md0304114p3 documenatation <<

Text preview - extract from the document

                                                                                                        ORDER NO. MD0304114P3




SA-PM147GC-K
   Please revise the original parts list in the Service Manual to conform to the change(s) shown herein.
   If new part numbers are shown, be sure to use then ordering parts.

Reason for Change
*The circled item indicates the reason. If no marking, see the Notes in the bottom column.
 O 1. Improve performance
   2. Change of material or dimension
   3. To meet approved specification
   4. Standardization
   5. Addition
   6. Deletion
   7. Correction
   8. Other

Interchangeability Code
**The circled item indicates the interchangeability. If no marking, see the Notes in the bottom column.
      Parts              Set Production
    A Original           Early            Original or new parts may be used in early or late production set.
      New                Late             Use original parts until exhausted, then stock new parts.
    B Original           Early            Original parts may be used in early production sets only. New parts may be used in early
      New                Late             or late production sets. Use original parts where possible, then stock new parts.
 O C Original            Early            New parts only may be used in early or late production sets.
      New                Late             Stock new parts.
    D Original           Early            Original parts may be used in early production sets only. New parts may be used in late
      New                Late             production sets only. Stock both original and new parts.
    E Other



Part Number
  Model No.       Ref. Original Part No. New Part No. Notes Part Name &  Remarks
                   No.                                      Descriptions
SA-PM147GC- C718 ECU1V1A124KB ECJ1VB1A124K 1,C CAPACITOR CHANGE [M]
K                               V
[M] indicates parts that are supplied by MESA.

   File this Parts Change Notice with your copy of the Service Manual for :
      Model No. SA-PM147GC-K                                     ORDER NO. MD0208205C3

   T.I No. M08603 (For Factory Reference only).
