Image preview - the first page of the document



>> Download Panasonic_CF-WCM314_Web_Camera_Kit documenatation <<

Text preview - extract from the document

         Web Camera Kit

Model No. CF-WCM314
                                            WARNING
For U.K.
       This apparatus must be earthed for your safety.
       To ensure safe operation the three-pin plug must be inserted only into a standard three-pin power point
       which is effectively earthed through the normal household wiring.
       Extension cords used with the equipment must be three-core and be correctly wired to provide connec-
       tion to earth. Wrongly wired extension cords are a major cause of fatalities.
       The fact that the equipment operates satisfactorily does not imply that the power point is earthed and
       that the installation is completely safe.
       For your safety, if you have any doubt about the effective earthing of the power point, consult a quali-
       fied electrician.
       FOR YOUR SAFETY PLEASE READ THE FOLLOWING TEXT CAREFULLY
       This appliance is supplied with a moulded three pin mains plug for your safety and convenience.
       A 3 amp fuse is fitted in this plug.
       Should the fuse need to be replaced please ensure that the replacement fuse has a rating of 3 amps and
       that it is approved by ASTA or BSI to BS 1362.

       Check for the ASTA mark          or the BSI mark      on the body of the fuse.
       If the plug contains a removable fuse cover you must ensure that it is refitted when the fuse is replaced.
       If you lose the fuse cover the plug must not be used until a replacement cover is obtained.
       A replacement fuse cover can be purchased from your local Panasonic Dealer.
       IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR
       HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED
       OF SAFELY.
       THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE CUT OFF PLUG IS INSERTED
       INTO ANY 13 AMP SOCKET.
       If a new plug is to be fitted please observe the wiring code as shown below.
       If in any doubt please consult a qualified electrician.
       Warning: THIS APPLIANCE MUST BE EARTHED.
       Important
       The wires in this mains lead are coloured in accordance with the following code:
       Green-and-yellow:         Earth
       Blue:                     Neutral
       Brown:                   Live
       As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured
       markings identifying the terminals in your plug, proceed as follows:
       The wire which is coloured GREEN-and-YELLOW must be connected to the terminal in the plug
       which is marked by the letter E or by the safety earth symbol        coloured GREEN or GREEN-and-
       YELLOW.
       The wire which is coloured Blue must be connected to the terminal which is marked with the letter N or
       coloured BLACK.
       The wire which is coloured Brown must be connected to the terminal which is marked with the letter L
       or coloured RED.

       The mains plug on this equipment must be used to disconnect the mains power.
       Please ensure that a socket outlet is available near the equipment and shall be easily accessible.
            How to replace the fuse
       Open the fuse compartment with a screw-
       driver and replace the fuse.



       Warnings
        This equipment is not designed for connection to an IT power system.
        (An IT system is a system having no direct connections between live parts and Earth; the exposed-conducive-
        parts of the electrical installation are earthed.
        An IT system is not permitted where the computer is directly connected to public supply systems in the U.K.)
           Disconnect the mains plug from the supply socket when the computer is not in use.

       This equipment is produced to BS800/1983.


                                                         2   /   1 8
                LASER SAFETY INFORMATION
For U.S.A.
    Class 1 LASER-Product
    This product is certified to comply with DHHS Rules 21 CFR Subchapter J.
    This product complies with European Standard EN60825 (or IEC Publication 825)
    For all areas
    This equipment is classified as a class 1 level LASER product and there is no hazardous LASER radiation.

     Caution:
     (1) Use of controls or adjustments or performance of procedures other than those specified herein
          may result in hazardous radiation exposure.
     (2) The drive is designed to be incorporated into a computer-based system or unit which has
          an enclosing cover. It should never be used as a stand alone drive.


     Danger:
     The serviceman should not remove the cover of drive unit and should not service because
     the drive unit is a nonserviceable part.
     Please check DANGER label on PD-drive unit.
