Image preview - the first page of the document

>> Download 4393 - disassembly (section 2) documenatation <<

Text preview - extract from the document

DISASSEMBLY PROCEDURES

CONTENTS
1. Note when inserting Flexible Cable ..........................................................................................DIS-1
2. Disassembly Flowchart.............................................................................................................DIS-1
3. Removal of MIC Case Unit .......................................................................................................DIS-2
4. Removal of Side Case R Unit...................................................................................................DIS-3
5. Removal of POWER C.B.A. .....................................................................................................DIS-4
6. Removal of TOP VF Unit ..........................................................................................................DIS-5
7. Removal of Front Case Unit .....................................................................................................DIS-6
8. Removal of Lens Unit ...............................................................................................................DIS-7
9. Removal of Rear Case Unit & CAMERA C.B.A. ......................................................................DIS-8
10. Removal of Cassette Cover Unit ..............................................................................................DIS-9
11. Removal of Mechanism Unit & VTR C.B.A. .............................................................................DIS-10
12. Removal of LCD Unit................................................................................................................DIS-12
13. Removal of EVF Unit ................................................................................................................DIS-13
1. Note when inserting Flexible Cable

The flexible cables, have two sets of contacts on each cable, see the figure below. When inserting these cables
into the connector, make sure that the cables are fully inserted, if not they may damage the connector.

CONNECTOR
FLEXIBLE CABLE
(REAR SIDE)

TWO CONTACT
POINTS

2. Disassembly Flowchart

3. MIC Case Unit

4. Side Case R Unit

5. POWER C.B.A. 11. LCD Unit

6. TOP VF Unit

7. Front Case Unit 12. EVF Unit

8. Lens Unit

9. Rear Case Unit & CAMERA C.B.A.

10. Cassette Cover Unit

11. Mechanism Unit & VTR C.B.A.

DIS-1
3. Removal of MIC Case Unit

1. Unscrew the 6 screws (A) and remove the MIC Case Unit as shown in figure 3-1.

MIC CASE UNIT
SCREW (A) SCREW (A)

Remove the Hood unit, before disassembly of unit.

Figure 3-1

DIS-2
4. Removal of Side Case R Unit

1. Remove the MIC Case Unit.
2. Unscrew the 10 screws (A) as shown in figure 4-1.
3. Disconnect the connector P6403 on R SIDE C.B.A. and remove the Side Case R Unit as shown in figure 4-1.

SCREW (A)

SIDE CASE R UNIT

SCREW (A)

P6403

Figure 4-1

DIS-3
5. Removal of POWER C.B.A.

1. Remove the MIC Case Unit.
2. Remove the Side case R Unit.
3. Disconnect a connector P1001 on POWER C.B.A. as shown in figure 5-1.
4. Unscrew the 2 screws (A) and remove the POWER C.B.A.. Be careful because the CAMERA C.B.A.(bottom
side of POWER C.B.A.) and the connector in the POWER C.B.A are combining the one connector.
(Note in installation)
1. In case new POWER C.B.A. is installed, put the Cooling Sheet in following position as shown in figure 5-1.

SCREW (A)

There is a direct connector in
the backward.

COOLING SHEET
(Two sheet)

COOLING SHEET POWER C.B.A. P1001 SCREW (A)

Figure 5-1

DIS-4
6. Removal of TOP VF Unit

1. Remove the MIC Case Unit.
2. Remove the Side Case R Unit.
3. Unscrew the 4 screws (A) as shown in figure 6-1.
4. Lift up the TOP VF and disconnect a connector P2215 on VTR C.B.A., then remove the TOP VF Unit as
shown in figure 6-1. Then be careful because the portion A and B are hooked together.
(Note in installation)
1. In case the flexible cable (A) is changed to new one, bend it to Z character as shown in figure 6-1.
2. The CCD Heat Sink is located to outside of TOP VF Unit as shown in figure 6-1.

TOP VF UNIT

SCREW (A)

B
SCREW (A)

A
Hook the A to B portion.

Flexible Cable (A)

P2215

Do not give
damage to cable Outside of TOP VF Unit

Figure 6-1

DIS-5
7. Removal of Front Case Unit

1. Remove the MIC Case Unit.
2. Remove the Side Case R Unit.
3. Remove the TOP VF Unit.
4. Unscrew the 3 screws (A) as shown in figure 7-1.
5. Disconnect a connector P6301 and remove the Front Case Unit as shown in figure 7-1.
(Note in installation)
1. When installing the Front Case Unit, do not give damage the Lens.
2. In case of the flexible cable (it connected with P6301 and CAMERA C.B.A.) is exchange to new one, bend it
to Z character to put under the Lens Unit.

Be careful not to damage the lens.

FRONT CASE UNIT

P6301

SCREW (A)

Bend flexible cable to put under the Lens Unit.

Figure 7-1

DIS-6
8. Removal of Lens Unit

1. Removal of MIC Case Unit.
2. Removal of Side Case R Unit.
3. Removal of POWER C.B.A..
4. Removal of TOP VF Unit.
5. Removal of Front Case Unit.
6. Unscrew the 2 screws (A) and remove the CCD CON STOPPER as shown in figure 8-1.
7. Disconnect the connector P1 and P8 on CAMERA C.B.A. as shown in figure 8-1.
8. Unscrew the 4 screws (B) and remove the Lens Unit.
9. Unscrew the 4 screws (C) and remove the Lens Frame Unit from Lens Unit as shown in figure 8-1.
(Note in installation)
1. In case a new Lens Unit is installed, bend the flexible cable (A) to Z character as shown in figure 8-1.

LENS UNIT Bend to Z character

SCREW (B)

(A)

SCREW (A)
P8 P1

SCREW (B)

CCD CON STOPPER

Lens Frame Unit

SCREW (C)

Figure 8-1

DIS-7
9. Removal of Rear Case Unit & CAMERA C.B.A.

1. Removal of MIC Case Unit.
2. Removal of Side Case R Unit.
3. Removal of POWER C.B.A..
4. Removal of TOP VF Unit.
5. Removal of Front Case Unit.
6. Removal of Lens Unit.
7. Remove the 3 screws (A) as shown in figure 9-1.
8. Disconnect a connector P2 on CAMERA C.B.A. as shown in figure 9-1.
9. Unscrew the 2 screws (B) on CAMERA C.B.A. as shown in figure 9-1.
10. It shifts the Rear Case Unit as much as showing in figure 9-1 and remove the CAMERA C.B.A.. Be careful
because the VTR C.B.A.(bottom side of CAMERA C.B.A.) and the connector in the CAMERA C.B.A are
combined.
11. Disconnect a connector P2216 on VTR C.B.A. and remove the Rear Case Unit.
(Note in installation)
1. When installing the CAMERA C.B.A., Attach the CAMERA C.B.A. to portion "A" of Mech. Attachment Frame
as shown in figure 9-1.
2. When installing the CAMERA C.B.A., the parts which are shown in figure 9-1 on the CAMERA C.B.A. are
combined with the VTR C.B.A. with the direct connector, pushing CAMERA C.B.A. well.
3. When installing the Rear Case Unit, it puts section "B" in the hole of flexible cable, which is connected in
P2216 as shown in figure 9-1.

There is a direct connector in
SCREW (B)
the bottom and push well.

SCREW (A)
CAMERA C.B.A

Hook to Frame. P2

REAR CASE UNIT

SCREW (A)

SCREW (A)
P2216

Figure 9-1

DIS-8
10. Removal of Cassette Cover Unit

1. Remove the MIC Case Unit.
2. Remove the Side case R Unit.
3. Remove the POWER C.B.A..
4. Remove the TOP VF Unit.
5. Remove the Front Case Unit.
6. Remove the Lens Unit.
7. Remove the Rear Case Unit and CAMERA C.B.A..
8. Unscrew the 2 screws (A) and remove the Cassette Cover Unit as shown in figure 10-1.

SCREW (A)

Figure 10-1

(Note in installation)
1. Pass flexible cable through the portion "A" as shown in figure 10-2.
2. Attach the "B" portion to "C" portion as shown in figure 10-2 and tighten the 2 screws (A).

CASSETTE COVER UNIT

B
C

Figure 10-2

DIS-9
11. Removal of Mechanism Unit & VTR C.B.A.

1. Remove the MIC Case Unit.
2. Remove the Side Case R Unit.
3. Remove the POWER C.B.A..
4. Remove the TOP VF Unit.
5. Remove the Front Case Unit.
6. Remove the Lens Unit.
7. Remove the Rear Case Unit and CAMERA C.B.A..
8. Remove the Cassette Cover Unit.
9. Disconnect the connector P2219 and P2222 on VTR C.B.A. as shown in figure 11-1.
10. Disconnect the connector P2217 on VTR C.B.A. and P4101 on SIDE JACK C.B.A., then remove the flexible
cable (A) as shown in figure 11-1.
11. Unscrew the 6 screws (A) and remove the Unit (Mechanism & VTR C.B.A.) as shown in figure 11-1.

SCREW (A)
Cooling Sheet P2219

P2222
A
SCREW (A)

P2217 P2222
SCREW (A)

Flexible Cable P2217
(A)

P4101

(Connection of A, B and C)

P4101
SCREW (A)

SIDE CASE L UNIT

Figure 11-1

NOTE: MECH Attachment Frame requires replacement, make sure to move the Cooling Sheet to the new MECH
Attachment Frame. See figure 11-1.

DIS-10
12. Disconnect the 7 connectors (A),(B),(C),(D),(E),(F) and (G) on VTR C.B.A. as shown in figure 11-2.

(G)
(A)

(B) (C) (D) (E) (F)

Figure 11-2

13. Unscrew the 2 screws (B) and remove the VTR C.B.A. as shown in figure 11-3.
14. Unscrew the 3 screws (C) and remove the Mechanism Unit from Mech. Attachment Frame Unit as shown in
figure 11-3.
15. Unscrew the 2 screws (D) and remove the Garage Cover as shown in figure 11-3.
NOTE: In case a new Mechanism unit is installed, put the FPC Protection Sheet in the following position as
shown in figure 11-3.

SCREW (B) Hook to Mech. Attachment Frame Unit

SCREW (D) Garage Cover

SCREW (B)

VTR C.B.A

SCREW (C)

Mech. Attachment Frame Unit

FPC Protection Sheet

Mechanism Unit

Put sheet at the end of the mechanic chassis.

Figure 11-3

DIS-11
12. Removal of LCD Unit

1. Remove the MIC Case Unit.
2. Remove the Side Case R Unit.
3. Unscrew the 3 screws (A) and remove the HEAT SINK(SIDE R) as shown in figure 12-1.
4. Remove the FFC Protection Sheet as shown in figure 12-2.
5. Remove the Cooling Sheet to unscrew the screw (B) and unscrew the screw (B) and (C) as shown in figure
12-2.
6. Remove the HINGE COVER and unscrew the 2 screws (D) as shown in figure 12-3.
7. Disconnect connector P6404 on R SIDE C.B.A. and remove the LCD Unit as shown in figure 12-2.
(Note in installation)
1. When installing the FFC Protection Sheet, fully open the LCD Panel and Put on the original position as shown
in figure 12-2.
2. Do not forget put on the Cooling Sheet after tightening the screw (B) as shown in figure 12-2.

HEAT SINK (SIDE R)

SCREW (A)

SCREW (A)
Figure 12-1

Cooling Sheet SCREW (B)

FFC Protection Sheet

P6404

SCREW (C)

Figure 12-2

HINGE COVER

SCREW (D) LCD PANEL UNIT

Figure 12-3

DIS-12
13. Removal of EVF Unit

1. Removal of MIC Case Unit.
2. Removal of Side Case R Unit.
3. Removal of TOP VF Unit.
4. Disconnect connector P1 on EVF CONNECT C.B.A. as shown in figure 13-1.
5. Unscrew the 4 screws (A) and remove the EVF Unit and EVF SLIDER Unit from EVF LCD HOLD Unit as
shown in figure 13-2.
6. Unscrew the 3 screws (B) and remove the EVF SLIDE COVER as shown in figure 13-3.
7. Unscrew the 4 screws (C) and remove the EVF Unit from EVF SLIDER Unit as shown in figure 13-4.

SCREW (A)

EVF LCD HOLDER UNIT

TOP VF UNIT

FPC

EVF SLIDE UNIT

P1
EVF UNIT

Figure 13-1 Figure 13-2

EVF SLIDE UNIT FPC

EVF SLIDE COVER SCREW (C)

Lift up EVF
SCREW (C)
Slide to EVF SCREW (B)

EVF UNIT

SCREW (B)

Figure 13-3 Figure 13-4

DIS-13
