Image preview - the first page of the document



>> Download vqt2l71 documenatation <<

Text preview - extract from the document

           Basic Operating Instructions
                                             Digital Camera
                               Model No.     DMC-TZ10




                   Before use, please read these instructions
                                                 completely.


 Please also refer to Operating Instructions (PDF
 format) recorded on the CD-ROM containing the
 Operating Instructions (supplied).
 You can learn about advanced operation methods and check the
 Troubleshooting.




                   Web Site: http://www.panasonic-europe.com

Model number suffix "EB" denotes UK model.
EB                                                         VQT2L71
Dear Customer,                                                              Caution for AC mains lead                    As these colours may not correspond
We would like to take this opportunity to thank you for purchasing this     For your safety, please read the             with the coloured markings identifying
Panasonic Digital Camera. Please read these Operating Instructions          following text carefully.                    the terminals in your plug, proceed as
                                                                                                                         follows:
carefully and keep them handy for future reference. Please note that the    This appliance is supplied with a            The wire which is coloured Blue must
actual controls and components, menu items, etc. of your Digital Camera     moulded three pin mains plug for your        be connected to the terminal which is
may look somewhat different from those shown in the illustrations in        safety and convenience.                      marked with the letter N or coloured
                                                                            A 5-ampere fuse is fitted in this plug.      Black or Blue.
these Operating Instructions.                                               Should the fuse need to be replaced          The wire which is coloured Brown must
                                                                            please ensure that the replacement           be connected to the terminal which is
Carefully observe copyright laws.                                           fuse has a rating of 5-ampere and that it    marked with the letter L or coloured
